Compressor coolant , 104L2123,Compresseur Danfoss SC18CL – R404A, R449A, R407A, R452A,R404a/R507, SC18CL, 220-240V 50Hz, LBP/MBP, 5/8HP , CSR,LRA 20A, 3.25A , 715W, 210*85 freezer

image_pdfimage_print

Compressor Danfoss Secop SC18CL, SC18CLX, 104L2123, LBP / HBP – R404A, R507, 220-240V/1/50Hz, discharge 17.69 cm3, motor type CSR, oil type POE, oil charge 600 cm3, 715 W at -25 / 55° C, LRA 20 A, maximum refrigerant charge 1300 g, height: 219 mm, weight 13.7 kg


Refrigerant: R507a R404A
Power range(W): 701 – 1000 W 1 – 1,5 kW
Performance range (C): -45 C to -5 C
Working area: LBP HBP
Design type: Hermetic
Model series: SC
Use with: Expansion/Capillary
Power supply: 230 V
Oil type: POE
Engine type: CSR
Article condition: New
Info: Oil filled
Shipping weight: 15,70 Kg
Contents: 1,00 Pieces
Dimensions ( height ): 21,90 cm
Cooling capacity condition: T0 -15 C
Manufacturer: Danfoss Secop
Model: SC18CL
Modelname: 104L2123
Modellname 3: SC18CLX
Stroke volume (cm3): 17,69
Performance condition: -25 / +55 °C
Power (W): 715
Cooling capacity (W): 1154
Max. Starting current (A): 20
Engine type: CSR
Note: Maximum refrigerant amount 1300 g
Oil quantity (l): 0,6
Compressor type: Piston
Power range: -45 C to -5 C

Compressor DANFOSS SC18CL 104L2123
