Compressor, ACC Cubigel, Huayi, Electrolux, ZEM GL99AA, GL99AA, LBP , R134a, 220-240V/1/50Hz, 1/4 HP, discharge 9.93 cm3, motor type RSIR, LRA 14.4A,

image_pdfimage_print

Compressor ACC Cubigel Huayi Electrolux ZEM GL99AA, LBP – R134a, 220-240V/1/50Hz, 1/4 HP, discharge 9.93 cm3, motor type RSIR, LRA 14.4A, expansion device: capillary, cooling: static,weight 11 kg , the statutory warranty period shall apply (24 months), Delivery time Info: with “immediately available” and “scarce stock”, usually delivery within 2 days. For “currently not available” delivery time usually 2 weeks or delivery time in urgent cases contact us.


Refrigerant:R134a
Power range(W):101 – 200 W
Performance range (C):-35 C to -10 C
Connecting size:4,9 mm
Suction:6,5 mm
Working area:LBP
Design type:Hermetic
Model series:GL
Use with:Capillary
Power range(HP):0-2
Power supply:230 V
Oil type:ISO VG 22 Ester
Engine type:RSIR
Article condition:New
Info:Oil filled
Shipping weight:13,00 Kg
Dimensions ( length × width × height ):23,10 × 16,20 × 18,60 cm
Cooling capacity condition:T0 -25 C, Tk +55 C
Manufacturer:ACC Cubigel Huayi Electrolux ZEM
Model:GL99AA
Stroke volume (cm3):9,93
Cooling capacity (W):174
Power (HP):0,25
Max. Starting current (A):14,4
Max. Operating current (A):1,31
Engine type:RSIR
COP:0,92
Note:Static cooling
Conveying and suction volume (m3):1,72
Oil quantity (l):0,295
Compressor type:Piston
Cooling:Static
RPM:2900
Power range:-35 C to -10 C
Alternative:HLY90AA, NL11F
Pressure line (mm):4,9
Suction line (mm):6,5

Compressor, ACC Cubigel, Huayi, Electrolux, ZEM GL99AA, LBP , R134a, 220-240V/1/50Hz, 1/4 HP, discharge 9.93 cm3, motor type RSIR, LRA 14.4A,
