Séries
|
Ellipse
|
A (millimètre)
|
B (millimètre)
|
C (millimètre)
|
D (millimètre)
|
E (mm)
(ID)
|
F (mm)
(ID)
|
G (millimètre)
|
Dessin n °
|
|
SG
|
SG533F SG573F SG533Q SG513Q SG553Q
|
242,0.
|
193,0
|
65,0
|
99,0
|
8,2
|
9,8
|
54,5
|
N ° 1
|
|
SG633F SG633P SG653P SG673P SG733R SG555F-A
|
256,0
|
193,0
|
65,0
|
99,0
|
8,2
|
9,8
|
55,5
|
N ° 1
|
|
FG
|
FGA550-A
|
221,8
|
193,0
|
65,0
|
99,0
|
8,2
|
9,8
|
45,7
|
N ° 1
|
|
FG313S-A
|
242,0
|
193,0
|
65,0
|
99,0
|
8,2
|
9,8
|
54,5
|
N ° 1
|
|
CG
|
CG133B, CG533Q
|
242,0
|
193,0
|
65,0
|
99,0
|
8,2
|
9,8
|
55,5
|
N ° 1
|
|
SH
|
SH733H SH733Q SH833JSH833K
|
258,4
|
252,0
|
70,0
|
114,0
|
9.7
|
12,9
|
60,3
|
N ° 2
|
|
SH833K-G SH833U
|
270,4
|
262,5
|
80,0
|
120,5
|
9.7
|
12,9
|
60,3
|
N ° 2
|
|
SH773H SH773Q SHZ33L SHZ73L
|
278,4
|
252,5
|
70,0
|
114,0
|
9.7
|
12,9
|
60,3
|
N ° 2
|
|
SH933R SH973R
|
278,4
|
262,5
|
80,0
|
120,5
|
9.7
|
12,9
|
60,3
|
N ° 2
|
|
SH933R-S
|
293,4
|
220,5
|
70,0
|
114,0
|
9.7
|
12,9
|
60,3
|
N ° 2
|
|
SHZ83L-E SHY33M-G
SHYM-D SHY33M-E
SHY73M SHX33S
SHW33T SHW73T
|
293,4
|
262,5
|
80,0
|
120,5
|
9.7
|
12,9
|
60,3
|
N ° 2
|
|
SHV33Y-G SHV33Y
|
338,9
|
299,0
|
89,1
|
125,0
|
9.7
|
16.2
|
80,4
|
N ° 2
|
|
CH
|
CH933R-S CHY33M-S CHW33T
|
307,8
|
262,5
|
80,0
|
120,5
|
9.7
|
12,9
|
60,3
|
N ° 2
|
|
TH
|
THU33W
|
372,7
|
342,8
|
89,1
|
125,0
|
9.7
|
16.2
|
70,0
|
N ° 3
|
|
