Description
Compressor Refrigerant R600a GMCC PZ90H1Y SXF-562JA 1/5hp
Launcher(PTC) TY-QZ-003/QPE2-A15MD3
Protector DRB17T61A1/3TM158TF2/BT45-140A61D3
Condenser 3.0μF( CBB65 )
Diameter of tube (interior) 4.9±0.1
Voltage 220- 240V 50Hz
43 degree Voltage range 187-253
Refrigerant R600a
Capacity (cm³) 9
Weight (kg) 8.1±0.4
Cooling Capacity(W) 167
Input (W) 92.3
Current(A)0.47
Cop 1.81
Noise dB( A)40
