Mbsm.pro, Compressor, Hitachi, High Quality, Rotary, Sh356mv-C7nu, Air Conditioner, 2.4 HP, 19283 BTU, R22, 220 V, 1 PH, 5655 w

11 February 2022
 |  No Comments
image_pdfimage_print

Color: Black
Voltage: 220V 1p
Frequency: 50Hz
Horse Power: 2.8HP
Oil Charge: 1L
N.W.: 37kg
Product Description
 hitachi air conditioner compressor r22 refrigerant SH356MV-C7NU

Brand name Hitachi
Place of origin Japan
Model name SH356MV-C7NU
Application T3 Working Condition
Refrigerant R-22
Displacement 41.7ml/rev
Power 220-240v
Frequency 50Hz
Phase 1ph
Related capacity(w) 5655
BTU 19283
Description air conditioner compressor r22 refrigerant
Product Description

Model no Application Refrig-erant Displacem-ent Power supply Related capacity(w) HP BTU
SH286DG-C7HU T3 Working Condition R-22 28.6ml/rev 220V/60Hz/1PH 5895 2.5 20101
SH307MV-C7HU T3 Working Condition R-22 30.7ml/rev 220-240V/50Hz/1PH 5200 2 17732
SH307RV-C8LU T1 Working Condition R-22 30.7ml/rev 220-240V/50Hz/1PH 5200 2 17732
SH336DG-C8LU T3 Working Condition R-22 33.6ml/rev 220V/60Hz/1PH 5200 2 17732
SH336MV-C8LU T3 Working Condition R-22 33.6ml/rev 220-240V/50Hz/1PH 5655 2.3 19283
SH356DG-C8LU T3 Working Condition R-22 35.6ml/rev 220V/60Hz/1PH 5655 2.3 19283
SH356MV-C7NU T3 Working Condition R-22 35.6ml/rev 220-240V/50Hz/1PH 5655 2.3 19283
SH356MV-C8LU T3 Working Condition R-22 35.6ml/rev 220-240V/50Hz/1PH 6010 2.5 20494
SHV33YC1-E T3 Working Condition R-22 41.7ml/rev 220-240V/50Hz/1PH 6950 2.8 23699
SHV33YC6-G T1 Working Condition R-22 41.7ml/rev 220V/50Hz/1PH 7100 3 24211
SHV33YC6-S T1 Working Condition R-22 41.7ml/rev 220V/50Hz/1PH 7020 2.8 23938
SHV33YC6-U T1 Working Condition R-22 41.7ml/rev 220-240V/50Hz/1PH 7100 3 24211
SHV33ZC1-S T1 Working Condition R-22 40.0ml/rev 220V/50Hz/1PH 6770 2.7 23085
SHV33ZC1-U T1 Working Condition R-22 40.0ml/rev 220V/50Hz/1PH 6740 2.7 22983
SHV73YC1-E T3 Working Condition R-22 41.7ml/rev 208-230V/60Hz/1PH 8520 3.5 29053
SHV73YC1-U T1 Working Condition R-22 41.7ml/rev 208-230V/60Hz/1PH 8520 3.5 29053
SHW33TC4-E T3 Working Condition R-22 35.6ml/rev 220-240V/50Hz/1PH 6090 2.5 20766
SHW33TC4-S T1 Working Condition R-22 35.6ml/rev 220V/50Hz/1PH 6058 2.5 20657

Catalogue Hitachi DH serie Compressor

Type Model Refrigerant Colling Capacity Test Condition Motor Input Current COP Oil Charge
      BTU/H WATTS   WATTS RLA W/W L
STANDRAD TYPE 303DH-47C2 R22 29500 8650 380V 3~50Hz 2700 5 3.2 1.2
303DH-50C2 32220 9450 2900 5.4 3.2 1.2
353DH-56C2 35460 10400 3200 6.2 3.25 1.2
403DH-64C2 40240 11800 3600 6.8 3.25 1.2
453DH-72C2 46040 13500 4000 7.6 3.4 1.4
503DH-80C2 50800 14900 4400 8.1 3.4 1.4
503DH-83C2 52510 15400 4550 8.6 3.4 1.4
603DH-90C2 57290 16800 5100 9.5 3.3 1.4
603DH-95C2 60020 17600 5300 10 3.3 1.4
PARALLEL TYPE 303DH-47C2Y 29500 8650 2700 5 3.2 1.8
403DH-50C2Y 32220 9450 2900 5.4 3.2 1.8
353DH-56C2Y 35460 10400 3200 6.2 3.25 1.8
403DH-64C2Y 40240 11800 3600 6.8 3.25 1.8
453DH-72C2Y 46040 13500 4000 7.6 3.4 1.8
503DH-80C2Y 50800 14900 4400 8.1 3.4 1.8
503DH-83C2Y 52510 15400 4550 8.6 3.4 1.8
603DH-90C2Y 57290 16800 5100 9.5 3.3 1.8
603DH-95C2Y 60020 17600 5300 10 3.3 1.8

Hitachi series such as SD,SH are supplied.

Model name Power(w) HP Displacement Capacitance Cooling capacity (w) COP Capacitor μF / v Current A
SD074CV 415 0.55 0.74 220~240V/50Hz 1210 2.9 13 2
SD086CV 480 0.64 0.86 220~240V/50Hz 1410 2.94 15 2.3
SD091CV 520 0.69 0.91 220~240V/50Hz 1490 2.94 13 2.4
SD104CV 575 0.77 1.04 220~240V/50Hz 1740 3.03 15 2.75
SD122CV 690 0.92 1.22 220~240V/50Hz 2040 2.96 17 3.3
SD127CV 720 0.96 1.27 220~240V/50Hz 2050 2.92 17 3.5
SD134CV 750 1 1.34 220~240V/50Hz 2260 3.01 17 3.55
SD145CV 815 1.09 1.45 220~240V/50Hz 2480 3.04 20 3.9
SD156CV 870 1.16 1.56 220~240V/50Hz 2650 3.05 25
Model no Application Refrigerant Displacement  Power Supply Related capacity(w) BTU
SH286DG-C7HU T3 Working Condition R-22 28.6ml/rev 220V/60Hz/1PH 5895 20101
SH307MV-C7HU T3 Working Condition R-22 30.7ml/rev 220-240V/50Hz/1PH 5200 17732
SH307RV-C8LU T1 Working Condition R-22 30.7ml/rev 220-240V/50Hz/1PH 5200 17732
SH336DG-C8LU T3 Working Condition R-22 33.6ml/rev 220V/60Hz/1PH 5200 17732
SH336MV-C8LU T3 Working Condition R-22 33.6ml/rev 220-240V/50Hz/1PH 5655 19283
SH356DG-C8LU T3 Working Condition R-22 35.6ml/rev 220V/60Hz/1PH 5655 19283
SH356MV-C7NU T3 Working Condition R-22 35.6ml/rev 220-240V/50Hz/1PH 5655 19283
SH356MV-C8LU T3 Working Condition R-22 35.6ml/rev 220-240V/50Hz/1PH 6010 20494
SHV33YC1-E T3 Working Condition R-22 41.7ml/rev 220-240V/50Hz/1PH 6950 23699
SHV33YC6-G T1 Working Condition R-22 41.7ml/rev 220V/50Hz/1PH 7100 24211
SHV33YC6-S T1 Working Condition R-22 41.7ml/rev 220V/50Hz/1PH 7020 23938
SHV33YC6-U T1 Working Condition R-22 41.7ml/rev 220-240V/50Hz/1PH 7100 24211
SHV33ZC1-S T1 Working Condition R-22 40.0ml/rev 220V/50Hz/1PH 6770 23085
SHV33ZC1-U T1 Working Condition R-22 40.0ml/rev 220V/50Hz/1PH 6740 22983
SHV73YC1-E T3 Working Condition R-22 41.7ml/rev 208-230V/60Hz/1PH 8520 29053
SHV73YC1-U T1 Working Condition R-22 41.7ml/rev 208-230V/60Hz/1PH 8520 29053
SHW33TC4-E T3 Working Condition R-22 35.6ml/rev 220-240V/50Hz/1PH 6090 20766
SHW33TC4-S T1 Working Condition R-22 35.6ml/rev 220V/50Hz/1PH 6058 20657

Constant-Speed/India/R22 230V 50Hz
Series Model Displacement (cc/rev) Cooling capacity (w) Cooling capacity (btu/h) Cop Capacitor (Hf/v) Height (mm) Test condition
H SH286RY-C7PU1A 28.6 4900 16719 3.27 45/450 307.8 ASHRAE/T
SH295RY-C7PUA 29.5 5060 17265 3.24 35/450 293.4 ASHRAE/T
SH295RY-C7PU1A 29.5 5035 17179 3.25 45/450 307.8 ASHRAE/T
SH307RY-C8DUA 30.7 5250 17913 3.26 45/450 307.8 ASHRAE/T
SH370RY-C8LU 37 6400 21837 3.25 65/450 320.9 ASHRAE/T
SH380RY-C8DU 38 6555 22366 3.24 50/450 320.9 ASHRAE/T
SH417RY-C8DU 41.7 7160 24430 3.21 45/450 330.9 ASHRAE/T
SH280UY-C7HUA 28 4810 16412 16412 45/450 307.8 ASHRAE/T
SH286UY-C7PUA 28.6 4930 16821 3.36 45/450 307.8 ASHRAE/T
SH300UY-C7HUA 30 5100 17401 3.36 45/450 307.8 ASHRAE/T
SH370UY-C8LU 37 6400 21837 3.3 60/450 330.9 ASHRAE/T
Constant-Speed/India/R22/Tropical 230V 50Hz
Series Model Displacement (cc/rev) Cooling capacity (w) Cooling capacity (btu/h) Cop Capacitor (Hf/v) Height (mm) Test condition Test condition
H SH307MV*1 30.7 5250 17913 3.2 45/450 293.4 ASHRAE/T
SH336MV-1 33.6 5750 19619 3.18 55/450 307.8 ASHRAE/T
SH356MVM 35.6 6130 20916 3.11 50/450 307.8 ASHRAE/T
SH417MV-1 41.7 7170 24464 3.17 65/450 330.9 ASHRAE/T
Constant-Speed/R32 220V/240V 50Hz
Series Model Displacement (cc/rev) Cooling capacity (w) Cooling capacity (btu/h) Cop Capacitor (Hf/v) Height (mm) Test condition Test condition
H GSH190TV 19.0 4954 16903 3.00 40/450 293.5 ASHRAE/T
GSH232SV 23.2 5896 20117 2.91 60/400 298.5 ASHRAE/T
Constant-Speed/India/R41 OA 230V 50Hz
Series Model Displacement (cc/rev) Cooling capacity (w) Cooling capacity (btu/h) Cop Capacitor (Hf/v) Height (mm) Test condition Test condition
H ASH184TV 18.4 4440 15149 2.96 40/450 293.5 ASHRAE/T
ASH193TV 19.3 4575 15610 2.96 40/450 293.5 ASHRAE/T
ASH201RY 20.1 4845 16531 2.95 40/450 293.5 ASHRAE/T
ASH210RY 21.0 5120 17469 2.98 40/450 293.5 ASHRAE/T
ASH244RY 24.4 5770 19687 2.95 55/450 301.1 ASHRAE/T
Constant-Speed/R290 220V/240V 50Hz
Series Model Displacement (cc/rev) Cooling capacity (w) Cooling capacity (btu/h) Cop Capacitor (Hf/v) Height (mm) Test condition Test condition
H PSH307CV-C7HU 30.7 4566 15579 3.22 60/450 307.8 ASHRAE/T
PSH307HV-C8DU 30.7 4565 15576 3.45 45/450 307.8 ASHRAE/T
Constant-Speed/Middle East/R22 230V 60Hz
Series Model Displacement (cc/rev) Cooling capacity (w) Cooling capacity (btu/h) Cop Capacitor (Hf/v) Height (mm) Test condition Test condition
H SH264DG*2 26.4 5550 18937 3.2 40/450 288.4 ASHRAE/T
SH307DG*1 30.7 6580 22451 3.22 55/450 307.8 ASHRAE/T
SH325DG 32.5 6860 23406 3.22 55/450 307.8 ASHRAE/T
SH356DG-3 35.6 7450 25419 3.24 50/450 317.8 ASHRAE/T
