R134a (dehumidifier, water cooling device, etc.)
| R134a HBP (dehumidifier, water cooler, etc.) | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Theoretical exclusion amount (㎤) |
Rated output (W) |
Rated horsepower (HP) |
Starting method | Refrigeration capacity (W) | Operating coefficient (W / W) | Height (mm) |
Weight (kg) |
certification | ||||
| (-23.3 ℃) | W / 0 RC | W / RC | |||||||||||
| 50Hz | 60Hz | 50Hz | 60Hz | 50Hz | 60Hz | ||||||||
| Power Source (V / Hz) 100/100,110V; 50/60 Hz | |||||||||||||
| FE25Y (A) | 3.2 3.2 | 60 | 1/12 | RSCR | 316 | 387 | 2.32 | 2.39 | 151 151 | 6.2 6.2 | |||
| FE140Y | 3.5 3.5 | 110 110 | 1/8 | RSCR | 355 | 425 | 2.43 | 2.47 | 151 151 | 6.2 6.2 | |||
| FE140Y-ALC | 3.5 3.5 | 110 110 | 1/8 | RSCR | 355 | 425 | 2.43 | 2.47 | 151 151 | 6.2 6.2 | |||
| FE140Y-AA | 3.9 | 110 110 | 1/8 | RSIR | 425 | 2.24 | 161 | 5.8 | |||||
| FE140Y-AAC | 3.5 3.5 | 110 110 | 1/8 | RSCR | 336 | 395 | 2.28 | 2.31 | 151 151 | 5.8 | |||
| FH170Y-B | 4.2 4.2 | 120 | 1/7 | RSCR | 434 | 529 | 2.42 | 2.46 | 151 151 | 6.2 6.2 | |||
| FH220Y2-ALC | 5.0 5.0 | 160 | 1/5 | RSCR | 528 | 641 | 2.34 | 2.46 | 171 | 7.2 7.2 | |||
| FH250Y2 | 6.0 6.0 | 180 | 1/4 | RSCR | 711 | 790 | 2.41 | 2.47 | 173 | 7.6 | |||
| EE90Y2-Z | 7.9 | 190 | 1/4 | RSCR | 922 | 2.15 | 171 | 7.9 | VPC | ||||
| Power Source (V / Hz) 100/100,110V; 50/60 Hz | |||||||||||||
| FE140Y-B | 3.5 3.5 | 110 110 | 1/8 | RSIR | 415 | 2.24 | 151 151 | 6.2 6.2 | |||||
| FH170Y-B | 4.2 4.2 | 120 | 1/7 | RSCR | 434 | 529 | 2.42 | 2.46 | 151 151 | 6.2 6.2 | |||
| FH220Y2-B | 4.6 | 160 | 1/5 | RSIR | 580 | 2.32 | 171 | 7.1 7.1 | |||||
| FH250Y2-B | 6.0 6.0 | 180 | 1/4 | RSIR | 760 | 2.14 | 173 | 7.6 | |||||
| FH300Y2-B | 7.0 7.0 | 230 230 | 1/3 | RSCR | 853 | 2.28 | 173 | 7.6 | |||||
| EE90Y2-BZ | 7.9 | 230 230 | 1/3 | RSCR | 954 | 2.20 | 171 | 7.6 | UL | ||||
| Power Source (V / Hz) 220-240V; 50 Hz | |||||||||||||
| FE140Y-E | 3.5 3.5 | 110 110 | 1/8 | RSIR | 345 | 2.14 | 151 151 | 6.0 6.0 | TUV CCC |
||||
| FE140Y-E | 3.5 3.5 | 110 110 | 1/8 | RSCR | 346 | 2.31 | 151 151 | 6.0 6.0 | TUV CCC |
||||
| FH170Y-E | 4.2 4.2 | 120 | 1/7 | RSIR | 390 | 1.95 | 151 151 | 6.0 6.0 | TUV CCC |
||||
| FH170Y-E | 4.2 4.2 | 120 | 1/7 | RSCR | 420 | 2.16 | 151 151 | 6.0 6.0 | TUV CCC |
||||
| FH210Y-E | 4.6 | 150 | 1/6 | RSIR | 470 | 2.22 | 171 | 6.9 | TUV CCC |
||||
| FH210Y-E | 4.6 | 150 | 1/6 | RSCR | 480 | 2.42 | 171 | 6.9 | TUV CCC |
||||
| FH250Y2-E | 6.0 6.0 | 180 | 1/4 | RSIR | 635 | 2.22 | 173 | 7.6 | TUV CCC |
||||
| FH250Y2-E | 6.0 6.0 | 180 | 1/4 | RSCR | 649 | 2.44 | 173 | 7.6 | TUV CCC |
||||
| FH300Y2-E | 7.9 | 230 230 | 1/3 | RSCR | 820 | 2.10 | 173 | 7.6 | TUV CCC |
||||
| EH370Y2-E | 8.3 | 230 230 | 1/3 | RSCR | 830 | 2.04 | 173 | 7.6 | TUV | ||||
| Power Source (V / Hz) 220V; 60 Hz | |||||||||||||
| FE140Y-D | 3.5 3.5 | 110 110 | 1/8 | RSIR | 440 | 2.20 | 151 151 | 6.2 6.2 | KTL | ||||
| FH170Y-F | 4.2 4.2 | 120 | 1/7 | RSIR | 513 | 2.11 | 151 151 | 6.2 6.2 | KTL | ||||
| FH220Y2-F | 4.6 | 160 | 1/5 | RSIR | 570 | 2.28 | 171 | 7.2 7.2 | KTL | ||||
| FH220Y2-F | 4.6 | 160 | 1/5 | RSCR | 580 | 2.53 | 171 | 7.2 7.2 | KTL | ||||
| FH250Y2-F | 6.0 6.0 | 180 | 1/4 | RSCR | 780 780 | 2.40 | 173 | 7.6 | KTL | ||||
| FH300Y2-F | 7.9 | 230 230 | 1/3 | RSCR | 966 | 2.39 | 173 | 7.6 | KTL | ||||
| For low temperature | For high temperature | |
|---|---|---|
| Condensation temperature | 54.4 ℃ | 54.4 ℃ |
| Evaporation temperature | -23.3 ℃ | 7.2 ℃ |
| Suction gas temperature | 32.2 ℃ | 35 ℃ |
| Expansion valve total temperature | 32.2 ℃ | 46.1 ℃ |
| Ambient temperature | 32.2 ℃ | 32.2 ℃ |
