Mbsm.pro, compressor, EM Series, Embraco, EMY75HLC, 211 w, 1/4 hp, lbp, 750 btu, r134a

30 May 2022
 |  No Comments
image_pdfimage_print

General Data

Typehermetic reciprocating
Technology TypeOn-Off
displacement6.99 cm³
Cooling compressorStatic/NotControled/220
expansion devicecapillary tube
Horse Power1/4 hp
Power Supply220-240V 50Hz

Electrical Data

engine typeRSCR
Starting TorqueLST
Start Winding Resistance19.85 Ω at 25ºC
Run Winding Resistance13.1 Ω at 25ºC
Locked Rotor Amperage (LRA)26.7 A
Rated Load Amperage (RLA) at 60 Hz3 A

Mechanical Data

Oil Type ConfigurationESTER
Oil Type ViscosityISO7
Oil Charge150 ml
weight7.4 kg

Electrical Components

nameDescription
Motor Protection4TM232NFBYY-53
Run Capacitor4
Starting DevicePTC | 8EA17B3

Wiring Diagram

Mbsm_dot_pro_private_PDF___EMY75HLCTélécharger
AttachmentTypeLink
Mbsm_dot_pro_private_picture___EMY75HLCimage/jpegGet Link
Mbsm_dot_pro_private_picture__EMY75HLCimage/pngGet Link
Mbsm_dot_pro_private_picture_EMY75HLC-image/pngGet Link
Mbsm_dot_pro_private_picture_EMY75HLCimage/pngGet Link
Mbsm_dot_pro_private_picture_EMY75HLC-1-1image/pngGet Link
Mbsm_dot_pro_private_picture_EMY75HLC-1-2image/pngGet Link
Mbsm_dot_pro_private_picture_EMY75HLC-1-3image/pngGet Link
Mbsm_dot_pro_private_picture_EMY75HLC-1-3image/pngGet Link
Mbsm_dot_pro_private_picture_EMY75HLC-1image/pngGet Link
Mbsm_dot_pro_private_picture_EMY75HLC-2image/pngGet Link
Mbsm_dot_pro_private_picture_EMY75HLC-3image/pngGet Link
Mbsm_dot_pro_private_picture_EMY75HLC-3image/pngGet Link
Mbsm_dot_pro_private_PDF___EMY75HLCapplication/pdfGet Link
Embedded ImageImageView Image
Embedded ImageImageView Image
Embedded ImageImageView Image
Embedded ImageImageView Image
Mbsmgroup Logo
1/4 HP211 w750 btuCompressorEM SeriesEmbracoEMY75HLCLBPmbsm.pro
