Mbsm.pro, compressors, DZ120V1A, DZ120V1V, DZ120V1B, inverter, blcd, from 1320 to 4320 rpm, from 82 to 265 w input, cooling 293 btu to 904 , 1/3 hp, r600a, lbp - MBSM DOT PRO

Mbsm.pro, compressors, DZ120V1A, DZ120V1V, DZ120V1B, inverter, blcd, from 1320 to 4320 rpm, from 82 to 265 w input, cooling 293 btu to 904 , 1/3 hp, r600a, lbp

21 January 2024

Download Attachments

1 Mbsm_dot_pro_private_PDF_DZ120V1U
Added by: Lilianne File size: 11 MB
2 Mbsm_dot_pro_private_picture_DZ120V1U
Added by: Lilianne File size: 10 MB
3 Mbsm_dot_pro_private_picture_Toshiba-Compressor-DZ120V1D
Added by: Lilianne File size: 82 KB
4 Mbsm_dot_pro_private_picture___Toshiba-Compressor-DZ120V1D
Added by: Lilianne File size: 80 KB
5 Mbsm_dot_pro_private_picture__Toshiba-Compressor-DZ120V1D
Added by: Lilianne File size: 53 KB

R600a LBP DC Inverter
100V/220~240V/50~60Hz
Model	Displ(cm3)	Cooling Type	Motor Type	rpm	ASHRAE (-23.3/54.4/32.2ºC)					Shell Height
					Cooling Capacity			COP
					w	Kcal/h	Btu/h	W/W	Btu/Wh
DZ90V1C	9	ST	BLDC	1320	69	59	235	1.85	6.31	127
				1620	88	76	300	1.9	6.48
				3000	172	148	587	1.8	6.14
				4320	220	189	751	1.69	5.77
DZ90V1Q	9	ST	BLDC	1320	69	59	235	2	6.82	141
				1620	88	76	300	2.05	6.99
				3000	172	148	587	1.95	6.65
				4320	220	189	751	1.65	5.63
DZ100V1C	10	ST	BLDC	1320	82	71	280	1.88	6.41	127
				1620	101	87	345	1.9	6.48
				3000	180	155	614	1.85	6.31
				4320	250	215	853	1.69	5.77
DZ120V1C	12	ST	BLDC	1320	86	74	293	1.76	6.01	127
				1620	108	93	368	1.81	6.18
				3000	210	181	717	1.78	6.07
				4320	265	228	904	1.65	5.63
DZ150V1Z	15	ST	BLDC	1320	110	95	375	1.83	6.24	145
				4620	145	125	495	1.88	6.41
				3000	270	232	921	1.75	5.97
				4320	340	292	1160	1.6	5.46

R134a LBP
220V-240V~50/60Hz
Model	Displ(cm3)	Cooling Type	Motor Type	Power Frequency	ASHRAE (-23.3/54.4/32.2ºC)					Shell Height
					Cooling Capacity			COP
					w	Kcal/h	Btu/h	W/W	Btu/Wh
PE40E1J-4	4	ST	RSCR	220V-240V~50Hz	110	95	375	1.2	4.09	164
PE40E1J-4	4	ST	RSCR	220V-240V~60Hz	130	112	444	1.35	4.61	164
PE40E1H-4	4	ST	RSCR	220V-240V~50Hz	110	95	375	1.4	4.78	170
PE40E1H-4	4	ST	RSCR	220V-240V~60Hz	130	112	444	1.5	5.12	170
SE45E1J-4	4.5	ST	RSCR	220V-240V~50Hz	120	103	409	1.2	4.09	175
SE45E1J-4	4.5	ST	RSCR	220V-240V~60Hz	145	125	495	1.35	4.61	175
PE50E1F-4	4.5	ST	RSCR	220V-240V~50Hz	138	119	471	1.42	4.85	175
PE50E1F-4	4.5	ST	RSCR	220V-240V~60Hz	162	139	553	1.54	5.25	175
PE50H1F-4	5	ST	RSCR	220V-240V-50Az	155	133	529	1.6	5.46	178
PE50H1F-4	5	ST	RSCR	220V-240V~60Hz	180	155	614	1.63	5.56	178
PE55H1C-4	5.5	ST	RSCR	220V-240V~50Hz	170	146	580	1.55	5.29	178
PE55H1C-4	5.5	ST	RSCR	220V-240V~60Hz	198	170	676	1.65	5.63	178
PE65H1D-4	6.5	ST	RSCR	220V-240V~50Hz	195	168	665	1.45	4.95	178
PE65H1D-4	6.5	ST	RSCR	220V-240V~60Hz	220	189	751	1.55	5.29	178
PE65H1C-4	6.5	ST	RSCR	220V-240V~50Hz	195	168	665	1.55	5.29	178
PE65H1C-4	6.5	ST	RSCR	220V-240V~60Hz	220	189	751	1.65	5.63	178
PE75H1F-4	7.5	ST	RSCR	220V-240V~50Hz	220	189	751	1.4	4.78	178
PE75H1F-4	7.5	ST	RSCR	220V-240V~60Hz	250	215	853	1.5	5.12	178
PE75H1D-4	7.5	ST	RSCR	220V-240V~50Hz	220	189	751	1.5	5.12	178
PE75H1D-4	7.5	ST	RSCR	220V-240V~60Hz	250	215	853	1.6	5.46	178


R290 LBP
220V-240V~50Hz
SA30E1J	3	ST	RSIR	220V-240V~50Hz	130	112	444	1.3	4.44	178
PA30E1C	3	ST	RSCR	220V-240V~50Hz	135	116	461	1.65	5.63	178
PA35E1E	3.5	ST	RSCR	220V-240V~50Hz	162	139	553	1.52	5.19	178
PA35E1D	3.5	ST	RSCR	220V-240V~50Hz	165	142	563	1.6	5.46	178
PA35E1C	3.5	ST	RSCR	220V-240V~50Hz	170	146	580	1.65	5.63	178
PA45E1E	4.5	ST	RSCR	220V-240V~50Hz	205	176	699	1.55	5.29	178
PA45E1D	4.5	ST	RSCR	220V-240V~50Hz	205	176	699	1.6	5.46	178
PA45E1C	4.5	ST	RSCR	220V-240V~50Hz	205	176	699	1.65	5.63	178
PA50H1E	5	ST	RSCR	220V-240V~50Hz	240	206	819	1.55	5.29	178
PA50H1B	5	ST	RSCR	220V-240V~50Hz	240	206	819	1.7	5.8	178
PA59H1B	5.9	FC	RSCR	220V-240V~50Hz	290	249	989	1.7	5.8	178

Tags: 1/3 HP, blcd, Compressors, cooling 293 btu to 904, DZ120V1A, DZ120V1B, DZ120V1V, from 1320 to 4320 rpm, from 82 to 265 w input, INVERTER, mbsm.pro, R600A
