NE2134Z Compressor Specifications
Applications: Refrigerators, small freezers, and small refrigeration units
Brand: Often manufactured by Embraco (Aspera).
Type: Hermetic
Refrigerant: R134a
Voltage: 220-240V
Frequency: 50 Hz
Displacement: 14.3 cm³
Temperature Range: -35°C to -5°C
Compressor Embraco Aspera NE2134Z, LBP – R134a, 220 – 240V/1/50Hz, 1,/2 HP, discharge 14.28 cm3, LRA 17.00 A, motor type CSIR, lubricant type POE 22, lubricant charge 350 ml, 364 W at -23.3 / 54.4 °, expansion device: capillary or valve, cooling: fan cooling, weight 11.65 kg
| Refrigerant: | R134a |
| Power range(W): | 301 – 400 W |
| Working area: | LBP |
| Design type: | Hermetic |
| Model series: | NE |
| Use with: | Expansion/Capillary |
| Power range(HP): | 0-2 |
| Power supply: | 230 V |
| Oil type: | POE22 |
| Engine type: | CSIR |
| Article condition: | New |
| Info: | Oil filled |
| Shipping weight: | 13,70 kg |
| Content: | 1,00 Pieces |
| Dimensions ( Length × Width × Height ): | 24,20 × 17,80 × 20,60 cm |
| customs tariff number: | 84143081 |
| Cooling capacity condition: | -23,3 / +54,4 |
| Manufacturer: | Embraco Aspera |
| Model: | NE2134Z |
| Stroke volume (cm3): | 14,28 |
| Cooling capacity (W): | 364 |
| Power (HP): | 0,5 |
| Max. Starting current (A): | 17 |
| Engine type: | CSIR |
| Note: | Fan cooling necessary |
| Oil quantity (l): | 0,35 |
| Compressor type: | Piston |
| Alternative: | GP16FB |
