Refrigerant
R600a
Cooling capicity
98W
Input power
67W
Hose Power
1/8 HP
Temperature application
LBP
Displacement
6.2cm³
Working Current
0.49A
Voltage
220V~240V/50Hz
COP
1.46W/W
Motor type
RSCR
Cylinder capacity
6.2cm³
Weight
5.2±0.3kg
