Panasonic Refrigerator, Freezer Compressor, QB110C25CAXO , 1/3 Hp , csir, LBP, 273 w, 10.86 cm3

2 June 2020

Download Attachments

1 Mbsm_dot_pro_private_PDF_QB110C25CAXO
Added by: Lilianne File size: 35 KB

Panasonic Refrigerator Freezer Compressor QB110C25CAXO:Product Description

Rated Voltage	Model	Specification		Voltage Range
50Hz	60Hz
W	kcal/hr	RSIR	RSCR	W	kcal/hr	RSIR	RSCR
220V 50Hz/60Hz	QB51C99GAX0	128	110	1.14	/	157	135	1.17	/	170-250V/50HZ 187-242V/60HZ
QB57C11GAX0	146	126	1.18	/	175	151	1.22	/
QB66C16GAX0	165	142	1.20	/	200	172	1.27	/
QB77C18GAX0	202	174	1.21	/	224	193	1.27	/
QB91C24GAX0	236	203	1.19	/	255	219	1.22	/
QB110C25CAX0	273	235	1.18	/	279	240	1.19	/	170V-250V 50Hz 198V-242V 60Hz

Mbsm_dot_pro_private_PDF_file_compressor_matsushita__panasonic_125 Télécharger

Attachment	Type	Link
Mbsm_dot_pro_private_picture_QB110	image/jpeg	Get Link
Mbsm_dot_pro_private_picture_QB110-1-1	image/jpeg	Get Link
Mbsm_dot_pro_private_picture_QB110-1-2	image/jpeg	Get Link
Mbsm_dot_pro_private_picture_QB110C25Caxo	image/jpeg	Get Link
Mbsm_dot_pro_private_picture_watt-compressor	image/jpeg	Get Link
Mbsm_dot_pro_private_picture_QB110C25Caxo-1	image/jpeg	Get Link
Mbsm_dot_pro_private_picture_watt-compressor-1	image/jpeg	Get Link
Mbsm_dot_pro_private_PDF_file_compressor_matsushita__panasonic_125	application/pdf	Get Link
Mbsm_dot_pro_private_picture_QB110C25CAXO	image/png	Get Link
Mbsm_dot_pro_private_PDF_QB110C25CAXO	application/pdf	Get Link
	Image	View Image
	Image	View Image
	Image	View Image
	Image	View Image
	Image	View Image

1/3 Hp(+big)CSIR Freezer Compressor Panasonic Refrigerator QB110C25CAXO

Tags: 1/3 Hp(+big), CSIR, Freezer Compressor, Panasonic Refrigerator, QB110C25CAXO
