Mbsm.pro, Compressor, ASF852HG, ROHS, 850 w, R134a, 1/4 hp++, 1/3 hp–, Hbp, relative, Aspera NEK6170Z

written by Lilianne | 11 March 2024

Compressor / Compressor ASF852HG HBP – R134a 208 – 230 V, 1Ph, 50 Hz.
Type of engine: CSIR.
displacement: 8.4 cm3.
Temperature range: HBP.
Suction pipe connection size: 8.10 mm.
Connection size pressure line: 6.10 mm. Weight: 10.4 kg.
Maximum height: 187.0 mm.
Power: 1/4 + hp. Efficiency: 2.07kcal / Wh.
Oil Type: ISO22.
Oil quantity: 350ml.
Starting torque: HST.

Compressor type: Reciprocating piston
Cooling capacity (W): 850
Design: Hermetic
Dimensions ( length × width × height ): 24.20 × 17.80 × 20.00 cm
Displacement (cm3): 8,39
Engine type: CSIR
Info: Oil prefilled
Manufacturer:
Max. Starting current (A): 12,4
Model series: ROHS
Oil quantity (l): 0,35
Oil type: ISO22, POE22
Power range (W): 852 w
Power range (hp): 0-2
Power supply: 400 V
Rated power (hp): 0.25++/0.3–
Refrigerant: R134a
Scope of application: HBP
Start-up torque: Start-up torque
To be used with: Capillary/Expansion
Type / Series: ASF852HG
Voltage: 230V/50Hz


Mbsm.pro, Danfoss, Compressor, 1/4hp++, hbp, 1/3 hp–, Fr10g, 134a, 103g6880,103g6890, 220v/1ph/50-60h

written by Lilianne | 11 March 2024

Refrigerants: R134a, Compressor power supply [V]: 220/1/50 220/1/60

Product details

Gross weight 10.6 Kg
Net weight 10.6 Kg
Gross weight 10.6 Kg
Net weight 10.6 Kg

Auxiliary winding resistance (start winding) for single-phase compressors [Ohm] 11.9
Auxiliary winding resistance (start winding) for single-phase compressors alt [Ohm] 11.9
Brand technique Reciprocating compressor
Capacity control Fixed speed
Colour Black
Compressor power supply [V] 220/1/50 220/1/60
Configuration code Single
Cut in current HST [A] 10.9 A
Cut in current LST [A] 15.1 A
Description FR10G
Discharge connection angle [°] 25 °
Discharge connection comments Al-cap
Discharge connection diameter [mm] 6.2 mm
Discharge connection material Cu-plated steel
Economizer No
Family FR
Free gas volume [cm3] 1350 cm³
Frequency [Hz] 50/60
Height from baseplate [mm] 191 mm
High value of nominal voltage at 50Hz [V] 230 V
High value of nominal voltage at 60Hz [V] 230 V
High value of voltage range at 50Hz [V] 254 V
High value of voltage range at 60Hz [V] 254 V
In scope of WEEE and contain batteries No
Length [mm] 243 mm
Liquid injection No
Low value of nominal voltage at 50Hz [V] 220 V
Low value of nominal voltage at 60Hz [V] 220 V
Low value of voltage range at 50Hz [V] 198 V
Low value of voltage range at 60Hz [V] 198 V
LRA HST 60Hz [A] 10.9 A
LRA HST [A] 10.9 A
LRA LST [A] 10.5 A
Main winding resistance for single-phase compressors [Ohm] 7.1
Model number FR10G
Motor type CSIR
RSIR
No. of phases (compressor) 1
No. of phases (fan) 1
Oil cooler connection comments Rubber cap
Oil cooler connection diameter [mm] 6.2 mm
Oil cooler connection material Copper
Oil quantity [cm3] 450 cm³
Oil type POE
Packing format Industrial pack
Phase 1
Process connection angle [°] 30 °
Process connection comments Al-cap
Process connection diameter [mm] 6.2 mm
Process connection material Cu-plated steel
Product group Hermetic compressors
Product Name Description Reciprocating compressor FR
Refrigerant charge [kg] [Max] 0.9 kg
RLA 2.20 A
Rotational speed at 50Hz [rpm] 2900 rpm
Rotational speed at 60Hz [rpm] 3500 rpm
Suction connection angle [°] 30 °
Suction connection diameter [mm] 8.2 mm
Suction connection material Cu-plated steel
Swept volume [cm3] 9.05 cm³
Technology Reciprocating
Total height [mm] 196 mm
Type FR10
Voltage 50Hz [V] 220 V
Voltage 50Hz [V] [Max] 240 V
Voltage 60Hz [V] 220 V
Voltage 60Hz [V] [Max] 240 V
Width [mm] 156 mm
Winding temperature short term [°C] [Max] 135 °C
Winding temperature stat [°C] [Max] 125 °C
Auxiliary winding resistance (start winding) for single-phase compressors [Ohm] 11.9
Auxiliary winding resistance (start winding) for single-phase compressors alt [Ohm] 11.9
Brand technique Reciprocating compressor
Capacity control Fixed speed
Colour Black
Compressor power supply [V] 220/1/50 220/1/60
Configuration code Single
Cut in current HST [A] 10.9 A
Cut in current LST [A] 15.1 A
Description FR10G
Discharge connection angle [°] 25 °
Discharge connection comments Al-cap
Discharge connection diameter [mm] 6.2 mm
Discharge connection material Cu-plated steel
Economizer No
Family FR
Free gas volume [cm3] 1350 cm³
Frequency [Hz] 50/60
Height from baseplate [mm] 191 mm
High value of nominal voltage at 50Hz [V] 230 V
High value of nominal voltage at 60Hz [V] 230 V
High value of voltage range at 50Hz [V] 254 V
High value of voltage range at 60Hz [V] 254 V
In scope of WEEE and contain batteries No
Length [mm] 243 mm
Liquid injection No
Low value of nominal voltage at 50Hz [V] 220 V
Low value of nominal voltage at 60Hz [V] 220 V
Low value of voltage range at 50Hz [V] 198 V
Low value of voltage range at 60Hz [V] 198 V
LRA HST 60Hz [A] 10.9 A
LRA HST [A] 10.9 A
LRA LST [A] 10.5 A
Main winding resistance for single-phase compressors [Ohm] 7.1
Model number FR10G
Motor type CSIR
RSIR
No. of phases (compressor) 1
No. of phases (fan) 1
Oil cooler connection comments Rubber cap
Oil cooler connection diameter [mm] 6.2 mm
Oil cooler connection material Copper
Oil quantity [cm3] 450 cm³
Oil type POE
Packing format Industrial pack
Phase 1
Process connection angle [°] 30 °
Process connection comments Al-cap
Process connection diameter [mm] 6.2 mm
Process connection material Cu-plated steel
Product group Hermetic compressors
Product Name Description Reciprocating compressor FR
Refrigerant charge [kg] [Max] 0.9 kg
RLA 2.20 A
Rotational speed at 50Hz [rpm] 2900 rpm
Rotational speed at 60Hz [rpm] 3500 rpm
Suction connection angle [°] 30 °
Suction connection diameter [mm] 8.2 mm
Suction connection material Cu-plated steel
Swept volume [cm3] 9.05 cm³
Technology Reciprocating
Total height [mm] 196 mm
Type FR10
Voltage 50Hz [V] 220 V
Voltage 50Hz [V] [Max] 240 V
Voltage 60Hz [V] 220 V
Voltage 60Hz [V] [Max] 240 V
Width [mm] 156 mm
Winding temperature short term [°C] [Max] 135 °C
Winding temperature stat [°C] [Max] 125 °C



Mbsm.pro, Jiaxipera, NS1121Y, 1/4 hp++, 1/3 hp–, 214Kcal, R600a, 220V

written by Lilianne | 11 March 2024

Compressor JIAXIPERA NS1121Y, LBP – R600a, 220-240V, 14.2 cm3. & nbsp;

220-240V, 50Hz, R600, LBP, 14.20cm3. Without capacitor.Condensing units Compressors : Compressor Manufacturer : JIAXIPERA Scope of application : LBPVoltage :220-240V



Mbsm.pro, Compressor, hpk190A, 1/4 hp++, 1/3 hp–, R600, HMBP, 220/240V, 50Hz, 12.11 cc , unionaire, UR-350, 340 L, R600a/48g, 0.87 A

written by Lilianne | 11 March 2024

Mbsm.pro, Compressor, hpk190A, 1/4 hp++, 1/3 hp–,R600,HMBP, 220/240V, 50Hz, 12,11 cc , unionaire, UR-350, 340 L, R600a/48g, 0.87 A



Mbsm.pro, Compressors, Danfoss, R134a, FR11G, 1/4 hp++, 1/3 hp–, HBP, 103g6980, 103g 6980, 103 g 6980, 195B0028, 103G6980

written by Lilianne | 11 March 2024

Compressors Danfoss R134a FR11G 195B0028 / 103G6980

Mbsm_dot_pro_private_PDF__103g6980 Mbsm_dot_pro_private_PDF_103g6980



Singlepack kits are complete compressor kits with all electrical and mounting accessories required for an installation or replacement. The singlepack lists provide the code numbers that are included in the kits. For comprehensive technical data on these code numbers, please refer to the individual code numbers.

TECHNICAL DATA

Model Displacement Refrigerant Voltage Evaporating
temperature range		 Lubricant
(Charge/Type		 Weight Max. Height
FR11G 11,15 cm3 R-134a 187-254V / 50Hz -30°C~+5°C – /450 ml 11,1 kg 196 mm

Cooling Capacity



Model Evaporating Temp. / Cooling Capacity R-134a
Condensing Temp. -30ºC -25ºC -20ºC -15ºC -10ºC -5ºC 0ºC +5ºC
FR11G 55 ºC 115 W 170 W 233 W 307 W 395 W 501 W 628 W 780 W



103G6980, compressor Secop / Danfoss FR11G, LBP / HBP- R134, 220
– 240V/1/50 Hz, discharge 11.15 cm3, motor type RSIR/CSIR, oil
type POE, oil charge 450 cm3, 170 W at -25 / 55° C, LRA 10 A,
maximum refrigerant charge 900 g, height: 196 mm, weight 10.6 kg
Refrigerant:



R134a

Power range(W):



101 – 200 W

Working area:



HBP LBP

Design type:



Hermetic

Model series:



Fr

Use with:



Expansion/Capillary

Power supply:



230 V

Oil type:



POE

Engine type:



CSIR RSIR

Article condition:



New

Info:



Oil filled

Shipping weight:
12,60 kg
Content:
1,00 Pieces
Dimensions ( Height ):
19,60 cm
customs tariff number:
84143081
Cooling capacity condition:
-25 / +55 °C
Manufacturer:
Danfoss Secop
Model:
FR11G
Modelname:
103G6980
Modellname 3:
FR11GX
Stroke volume (cm3):
11,15
Cooling capacity (W):
170
Max. Starting current (A):
10
Engine type:
RSIR
Note:
Maximum refrigerant quantity 900 g
Oil quantity (l):
0,45
Compressor type:
Piston
Others also bought:


Mbsm.pro, Compressor, Aspera, Embraco, EMT6170Z, R134a, 1/4 hp++, hbp, 1/3 hp–, lbp

written by Lilianne | 11 March 2024

Compresseur hermetique de Aspera – Embraco EMT6170Z – R134a

1/4+ HP

220-240V 50 Hz

Cylindrée =  7.69 CM3

APPLICATIONS = HBP

Moteur type: CSIR

Mbsm_dot_pro_private_PDF_EMT



CF1441G

written by Lilianne | 11 March 2024

Mbsm.pro, Freezer, CF1441G, 210 L, Compressor, 1/4 hp++, 1/3 hp–, R134a, 145g, 375w, 220v



Mbsm.pro, compressor, dle5.7cnt , Secop, Danfoss, 102H4685, 1/4 hp++, 1/3 hp–, r290

written by Lilianne | 11 March 2024

220/230V 50Hz
puissance 1/4 Hp – cylindrée 5,70 cc
gaz R290 LMBP
102H4686-HST DANFOSS

Mbsm_dot_pro_private_PDF_dle5.7cnt



Mbsm.pro, Compressor, SECOP, NL8F, R134A, 1/4 hp++, 1/3 hp–, 105g 6822, 105g6822

written by Lilianne | 11 March 2024

Chatgpt

Mbsm_dot_pro_private_PDF_Danfoss_R134A_220_240V_Compressors_Datasheets

The search results provide information on two different topics: a compressor with model number 105G6822 and an adhesive product called ET-HP. The compressor is a Secop NL8F model with a power of 1/4+ Hp and a displacement of 8 cc, using R134a LBP gas. ET-HP Adhesive is a two-part epoxy used to anchor threaded rod and rebar in concrete applications.





Mbsm.pro, Compressor, Embraco, FF10BKW, 1/4 hp++, 1/3 hp–, r12

written by Lilianne | 11 March 2024

FF10BKW appears to be a compressor model manufactured by Embraco . It is a 1/4+ horsepower compressor that uses inductive resistive start and captive start motors . It is used in refrigeration systems and has been replaced by the 30-FF10BK1 model

Mbsm_dot_pro_private_PDF_ff10bkw
