Mbsm.pro, compressor, L118CY, QD100, 193 w, r600a, 1/4 hp, 220-240V 50Hz, 1PH, LC-318, LC-368
![](https://www.mbsm.pro/wp-content/uploads/2024/03/Mbsm_dot_pro_private_picture__L118CY-compressor-pdf-1024x749.jpg)
Characteristics:
1. Strong load capacity
2. High efficiency & reliability
3. Reliable starting performance
4. Low noise
Specification of R134A Samsung Refrigerator Compressors
Rated Voltage (HP) | Model | Motot Type | Voltage | Cool capacity (w) | Cool capacity (BTU) | Input power (w) | COP (w/w) |
AC 200-220V | NC1A43KLB | PTC-RSCR | 220V 50Hz | 108 | 367 | 81.8 | 1.32 |
MSA141K-L1A | PTC-RSCR | 109 | 371 | 83.7 | 1.3 | ||
MSA141K-S1A | PTC-RSCR | 109 | 371 | 80.8 | 1.34 | ||
MSA141K-S1B | PTC-RSCR | 109 | 371 | 76.9 | 1.41 | ||
MSA143K-S1B | PTC-RSCR | 109 | 371 | 75 | 1.45 | ||
MSA151K-S1G | PTC-RSCR | 142 | 483 | 99.3 | 1.42 | ||
MSA162K-S1G | PTC-RSCR | 171 | 584 | 113.9 | 1.5 | ||
MSA170K-S1G | PTC-RSCR | 196 | 669 | 128.5 | 1.52 |
Type Number:CMA057LHEG
Type: Refrigeration compressor
Application: Refrigeration Parts, Medium Size Fridge/Freezer
Power Source: Electric
Source d’alimentation: 220-240V 50Hz
Product Name: LG Brand Refrigerator Compressor
Refrigerant gas: R134A
Fil Type: Alu-Fil
HP Cooling Capacity: 1/5HP
Compressor Condition: LG Original New
Accessory: PTC Relay, OLP, PTC Cover, Capacitor (M), Mounting Accessories
Tecumseh/Taikang piston compression AEA4440YES/AE4440YS detailed parameters:
product description
Product number | product type | application | refrigerant | Mains voltage/frequency | Version |
AEA4440YES (AE4440YS) | Piston | HBP – High Back Pressure | R-134a | 220V~60Hz | N/A |
Performance/Performance
condition | Test voltage | Cooling capacity | input power | efficiency | Evaporation temperature | condensation temperature | ambient temperature | Return air temperature | liquid temperature | ||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Btu/h | kcal/h | W | W | Btu/Wh | kcal/Wh | W/W | |||||||
ASHRAE | 220V ~ 60HZ | 4200 | 1058 | 1231 | 632 | 6.65 | 1.67 | 1.95 | 7.2°C (45°F) | 54°C (130°F) | 35°C (95°F) | 35°C (95°F) | 46°C (115°F) |
General/General
Evaporation temperature range: | -6.7°C to 12.8°C (20°F to 55°F) |
Motor torque: | High Start Torque (HST) |
Compressor cooling: | fan |
Mechanical/mechanical properties
weight: | 11 |
Weight unit: | KG |
Displacement (cc): | 12.04 |
Oil type: | N/A |
Viscosity (cSt): | N/A |
Oil volume (cc): | 0 |
Electrical/electricity
Voltage range (50 Hz): | N/A |
Voltage range (60 Hz): | 187-242 |
Locked Rotor Ampere (LRA): | 18 |
Rated load current (RLA 50 Hz): | 0 |
Rated load current (RLA 60 Hz): | 3.93 |
Maximum Continuous Current (MCC in Amps): | 0 |
Motor resistance (ohms) – Mainly: | 4.58 |
Motor resistance (ohms) – starting: | 18.82 |
Motor type: | CSIR |
Overload type: | N/A |
Relay type: | N/A |
Agency Approval/Agency Approval
Parameter
Product type | Reciprocating Compressor |
Series | CSB Series |
Speed type | Fixed speed |
Size | Small |
Displacement | 5.7 cc/rev |
Refrigerants | R600a |
Improvement order | Al Wire |
Rated voltage | 220-240 V |
Frequency | 50 Hz |
Operating type | RSIR |
Cooling Capacity | 100 W |
Application | LBP, Water Purifier Commercial Refrigeration |
Test condition | ASHRAE |
Evaporating temperature | -23.3°C |
Condensing temperature | 54.4°C |
Ambient temperature | 32.2°C |
