Compressor, R134A, GLY12RGA, 10,7cm³, HMBP, 230V, 3/8HP, CUBIGEL, HUAYI

written by Lilianne | 20 December 2021

Displacement (cm³)	Refrigerant	Application	Compressor Cooling	Voltage/Frequency	Frequency (Hz)	Motor Type	Cooling (kCal/h)	COP (W/W)	Cooling (W)	COP (W/W)	Technical Data Sheet (*)
GL45MG	4,56	R134a	HBP	S	230V 50/60Hz ~1	50	CSIR	352	1,95	340	1,67	GL45MG
GL45MG	4,56	R134a	HBP	S	230V 50/60Hz ~1	60	CSIR	412	1,92	398	1,65	GL45MG
GL60MG	5,98	R134a	HBP	S	230V 50/60Hz ~1	60	CSIR	520	2,02	499	1,73	GL60MG
GL60MG	5,98	R134a	HBP	S	230V 50/60Hz ~1	50	CSIR	445	1,99	427	1,70	GL60MG
GL80MG	7,57	R134a	HBP	S	230V 50/60Hz ~1	60	CSIR	702	2,15	674	1,84	GL80MG
GL80MG	7,57	R134a	HBP	S	230V 50/60Hz ~1	50	CSIR	600	2,10	576	1,78	GL80MG
GL90MG	8,85	R134a	HBP	S	230V 50/60Hz ~1	50	CSIR	685	2,10	661	1,79	GL90MG
GL90MG	8,85	R134a	HBP	S	230V 50/60Hz ~1	60	CSIR	800	2,11	772	1,83	GL90MG
GLY12RAa	10,70	R134a	HBP	F	220-240V 50Hz ~1	50	CSIR	900	2,30	867	1,97	GLY12RAa
GLY12RAb	10,70	R134a	HBP	F	220-240V 50Hz ~1	50	CSR	900	2,57	867	2,20	GLY12RAb
GLY12RGa	10,70	R134a	HBP	F	200-220/220-230V 50/60Hz ~1	50	CSIR	900	2,19	867	1,87	GLY12RGa
GLY12RGa	10,70	R134a	HBP	F	200-220/220-230V 50/60Hz ~1	60	CSIR	1.038	2,22	1.007	1,90	GLY12RGa
GLY12RGb	10,70	R134a	HBP	F	200-220/220-230V 50/60Hz ~1	50	CSR	900	2,32	867	1,98	GLY12RGb
GLY12RGb	10,70	R134a	HBP	F	200-220/220-230V 50/60Hz ~1	60	CSR	1.038	2,40	1.007	2,07	GLY12RGb
GP14TB	14,17	R134a	HBP	F	220-240V 50Hz ~1	50	CSIR	1.030	2,03	998	1,76	GP14TB
GP16TB	16,15	R134a	HBP	F	220-240V 50Hz ~1	50	CSIR	1.240	2,09	1.204	1,80	GP16TB
GP16TE	16,15	R134a	HBP	F	115V 60Hz ~1	60	CSIR	1.450	1,96	1.408	1,69	GP16TE
GP16TG	16,15	R134a	HBP	F	200-220/230V 50/60Hz ~1	50	CSIR	1.240	2,09	1.204	1,81	GP16TG
GP16TG	16,15	R134a	HBP	F	200-220/230V 50/60Hz ~1	60	CSIR	1.450	2,00	1.408	1,74	GP16TG
GPM16RA	16,15	R134a	HBP	F	220-240V 50Hz ~1	50	CSIR	1.351	2,09	1.317	1,79	GPM16RA

(*) Under standard conditions

Additional information

Voltage (V)	230Vac
Frequency (hz)	50
Range	MBP
Displacement (cm3)	10,7 cm³
Cooling capacity (W)	608W
Conditions (°C)	-10 / +45C
Refrigerant	R134A
Suction line	8.1mm juotettava
Liquid line	6,5mm juotettava
Height (mm)	198mm
Weight (kg)	10,43kg
Oil	ISO VG 32 Ester

Technical data

Model: GLY12RAa
Refrigerant Gas: R-134a
Pression/temperature: HBP
Power: 3/8 HP
Voltage: 230 V
Current Type: Single-Phase
Frequency: 50 Hz
Compressor Type: Hermetic
Displacement: 10.7 cm³
Power Cons. -10°C: 293 W
Power Cons. -5°C: 322 W
Efficiency 0°C: 351 W
Power Cons. +5°C: 380 W
Power Cons. +7,2°C: 392 W
T° Condensation: 40 °C
Cooling Cap. -15°C: 408 Kcal/h
Cooling Cap. -10°C: 512 Kcal/h
Cooling Cap. -5°C: 642 Kcal/h
Cooling Cap. 0°C: 797 Kcal/h
Cooling Cap. 5°C: 977 Kcal/h
Cooling Cap. 7.2°C: 1065 Kcal/h
Cooling Cap. 10°C: 1184 Kcal/h
Test Type: Ashare 46

Mbsm_dot_pro_private_PDF_pdf-GLY12RAa Télécharger

Compressor, NPT12FSC, CUBIGEL, R290, 12,10ccm, LBP, 3/8HP, 220 V 50/60 Hz

written by Lilianne | 20 December 2021

Technical Data Sheet
Compressor model NPT12FSC
Voltage 220-240V 50/60Hz ~1
Refrigerant R290
APPLICATION COMPRESSOR MOTOR
Application Low Back Pressure Displacement 12,10 cm³ Nominal Power 3/8 hp
Refrigerant R290 Diameter 27,00 mm Voltage/Frequency 220-240V 50/60Hz
Evaporating Temp. -40,0 ºC to -10,0 ºC Stroke 21,13 mm Voltage range 187-264 V
Expansion Capillar Net Weight 10,18 Kg Type ECM
Comp. Cooling Fan cooled Oil type ISO VG 32 ESTER Phase number 1 PH
Max. ambient temp. 43,0 ºC Oil charge 520 cm³ Locked Rotor Amps (LRA) 5,00 A
Max. Cont. Current (MCC) 3,70 A
Main W. resist. at 25ºC 6,70 Ω
Start W. resist. at 25ºC 6,70 Ω
NOMINAL PERFORMANCE – 3.000 RPM
ASHRAE CECOMAF
Cooling Capacity 585 kCal/h 508 W
COP 1,57 W/W 1,22 W/W
EER 1,35 kCal/Wh 1,06 kCal/Wh
Input Power 433 W 415 W
Current 3,43 A 3,30 A
TEST CYCLE CONDITIONS
ASHRAE CECOMAF
LBP (B) LBP (A)
Evaporating temp. -23,3 ºC -25,0 ºC
Condensing temp. 55,0 ºC 55,0 ºC
Liquid temp. 32,0 ºC 55,0 ºC
Ambient temp. 32,0 ºC 32,0 ºC
Suction temp. 32,0 ºC 32,0 ºC
Voltage/Frequency 220 V 50/60 Hz 220 V 50/60 Hz

Mbsm_dot_pro_private_PDF_Technical-Notes-NPT12FSC-1 Télécharger

Mbsm_dot_pro_private_PDF_danfoss_NPT12FSC_R290_220_5060 Télécharger

Electrolux Professional Compressor, R404a/R507, MX18FB, 220-240V, 50Hz, 17,3kg, 5/8HP, 571W, MX18 FB, CUBIGEL, LBP, HERMETIC COMPRESSOR, Zanussi ALF1103 Fridge

written by Lilianne | 20 December 2021

DESCRIPTION

MX18FB Cubigel ACC hermetic compressor

230V-50 Hz.
LBP.
power: 5/8 HP.
height: 221 mm.
suction connection: 3/8 “.
connection press: 5/16 “.
displacement cm³: 18.40.
gas type: R404A/R507.
SA = soldering connection
With the most extended models and 3 levels of efficiency – Standard, High and Very High – using the optional run capacitor concept.
The Cubigel range offers a solution for all cooling applications.
The P models are High back pressure compressors for R404A
Like refrigerators, freezers, bottle coolers, can coolers, ice cream freezers, vending machines, beer dispensers, soft drink dispensers and ice makers.
The most complete range of Cubigel compressors and Cubigel condensing units for every type of commercial application.
Cubigel is part of Huayi Compressor Co. Ltd. group in Barcelona, and specializes in designing, manufacturing and selling hermetic compressors and condensing units for the light commercial refrigeration market.
The Cubigel company focuses on a product innovation strategy based on a strong R&D team, enhanced know-how and more than 50 years of experience providing a broad range of solutions to the commercial refrigeration industry.

Mbsm_dot_pro_private_PDF_MX18FB-compresseur-acc-cubigell-electrolux-MX18FB Télécharger

Mbsm_dot_pro_private_PDF_TWB1374ygs-Motocompresores-y-Unidades-Tecumseh-Brasil-1 Télécharger

Tecumseh, Copeland, Compressor, Cross, Reference, P12FW, Compressor, R-12, 1/3HP, 230V, HMBP, ACC-ELECTROLUX, CUBIGEL/HUAYI

written by Lilianne | 20 December 2021

Type: Hermetic piston compressorsProducer: ACCSeries: HMBP
Model: P12FW
General data


Refrigerant:	R12
Discharge element:	C-V
Cooling:	F
Maximum ambient temperature [ºC]:	43

Compressor’s data


Cylinder capacity [cm³]:	12
Displacement [m³/h]:	2,1
Weight [kg]:	11,5
Oil charge [cm³]:	530
Oil type:	ISO VG 46 MINERAL

Engine’s data


Engine type:	CSIR
Power [KM]:	1/3
Starting element:	HST
Power supply:	220V 50Hz
Voltage range:	198-264
Locked rotor current [A]:	13,8
Running winding resistance (25ºC) [Ω]:	6,88
Starting winding resistance (25ºC) [Ω]:	26,97

Electrical data


Relays:	9660 A 145, MTRP 46
Shielding element:	MRT38AMK, T0168
Starting capacitor volume [μF]:

Connections

Mbsm_dot_pro_private_PDF_P12fw-FRIO Télécharger

	milimeters	inches
Suction/service tube:	8,1
Service/suction tube:	8,2
Discharge tube:	6,5

Mbsm_dot_pro_private_PDF_P12FW-1 Télécharger

Mbsm_dot_pro_private_PDF_P12fw Télécharger

ZMC, zanussi, Made in Egypt, Compressors

written by Lilianne | 20 December 2021

Mbsm_dot_pro_private_PDF_catalogo_cubigel_R134a Télécharger

Cubigel Compressors, Compressor, GQY80AT, 1/4Hp, LBP, R134a, 8.1cmc,165 W, REFRIGERATEUR INDESIT

written by Lilianne | 20 December 2021

Compresor GQY80AT, freon R134a, capacitate 8.1
cmc, capacitate frigorifica ASHRAE 222 W, capacitate
frigorifica CECOMAF 165 W, racire statica #GQY80AT
Model: GQY80AT
Freon: R134a
Capacitate: 8.1 cmc
Capacitate frigorifica ASHRAE: 222 W
Capacitate frigorifica CECOMAF: 165 W

35 -30 -25 -10 w COP
• 451.00.3301 GD40AAa / GVY40AA 1/10 S 4.03 34 49 70 0.77 154 C 200 6.7 RSIR P •
451.00.3202 GD40AA 1/10 S 4.03 34 49 70 0.77 154 C 200 6.7 RSIR P •
• 451.00.3302 GL45AA / GVY44AA 1/8 S 4.55 37 56 81 0.81 183 C 265 8.3 RSIR P •
• 451.00.3303 GL60AA / GVY57AA 1/6 S 5.99 50 75 107 0.85 238 C 265 9.1 RSIR P •
• 451.00.3304 GL75AA / GVY66AA 1/5 S 6.65 57 85 121 0.87 267 C 345 9.6 RSIR P •
• 451.00.3305 GL80AA / GVY75AA 1/5 S 7.52 68 101 144 0.89 326 C 345 9.9 RSIR P •
451.00.3104 GL80AAb 1/5 OC 8.10 68 101 144 0.89 326 C-V 345 9.9 CSIR R •
451.00.3005 GL90AA 1/4 S 9.08 82 119 165 0.90 350 C 345 10.2 RSIR P •
• 451.00.3306 GL90AAa / GQY80AT 1/4 S 9.08 82 119 165 0.90 350 C 345 10.2 RSIR P •
451.00.3105 GL90AAb 1/4 OC 9.08 82 119 165 0.90 350 C-V 345 10.2 CSIR R •
• 451.00.3205 GL90AAb 1/4 F 9.08 82 119 165 0.90 350 C-V 345 10.2 CSIR R •
• 451.00.3325 GL90AAa 1/4 OC 9.08 82 119 165 0.90 350 C-V 345 10.2 CSIR R •
451.00.3106 GP12BB 1/3 OC 12.00 83 131 190 0.88 424 C 400 11.5 RSIR R •
• 451.00.3206 GP12FB 1/3 F 12.00 83 131 190 0.88 424 C 400 11.5 RSIR R •
• 451.00.3326 GP12BB 1/3 OC 12.00 83 131 190 0.88 424 C 400 11.5 RSIR R •
451.00.3218 GP14CB 3/8 F 14.17 99 158 228 0.90 509 C 400 11.5 RSIR R •
451.00.3223 GP16FB 3/8 F 16.15 109 182 266 0.89 585 C-V 530 12.0 CSIR R •
451.00.3224 GX18FB 3/7 F 18.40 123 199 291 0.91 660 C-V 500 15.1 CSIR R •
451.00.3225 GX21FB 2/3 F 20.72 151 243 351 0.93 778 C-V 500 15.5 CSIR R •

451.00.3403 GL45TB 1/6 F 4.50 76 134 342 1.62 412 C-V 300 8.4 CSIR R •
• 451.00.3503 GL45PB 1/6 F 4.50 76 134 342 1.62 412 C-V 300 8.4 CSIR R •
451.00.3404 GL60TB 1/5 F 5.67 95 170 437 1.82 527 C-V 300 9.5 CSIR R •
• 451.00.3504 GL60PB 1/5 F 5.67 95 170 437 1.82 527 C-V 300 9.5 CSIR R •
451.00.3406 GL80TB 1/5 F 7.57 111 212 554 1.83 667 C-V 300 9.5 CSIR R •
• 451.00.3505 GL90TB 1/4 F 8.85 142 259 661 1.91 796 C-V 300 10.8 CSIR R •
• 451.00.3506 GP12TB 3/8 F 12.05 169 338 893 1.80 1077 C-V 350 11.2 CSIR R •
451.00.3418 GP14TB 3/8 F 14.00 190 373 999 1.77 1208 C-V 400 11.5 CSIR R •
• 451.00.3513 GP14TB 3/8 F 14.00 190 373 999 1.77 1208 C-V 400 11.5 CSIR R •
451.00.3419 GX18TB 1/2 F 18.40 285 539 1390 1.91 1673 C-V 500 16.0 CSIR R •
451.00.3420 GX21TB 5/8 F 20.72 332 603 1550 1.90 1866 C-V 500 17.0 CSIR R •
451.00.3421 GX23TB 5/8 F 23.20 368 677 1730 1.89 2083 C-V 500 17.0 CSIR R •
• 451.00.3422 GS26TB 3/4 F 25.93 392 771 2071 2.09 1011 C-V 887 22.7 CSIR R •
451.00.3423 GS30TB 7/8 F 29.95 317 785 2452 2.33 3020 C-V 887 22.7 CSR R •
• 451.00.3424 GS34TB 1 F 34.42 476 1068 2852 2.28 3421 C-V 887 22.7 CSR R •

Mbsm_dot_pro_private_PDF_GQY80AT Télécharger

Compressor, ACC, Cubigel, GL60AN, R134a, 220-240V, HMBP, 1/6HP

written by Lilianne | 20 December 2021

Type: Hermetic piston compressorsProducer: ACC Series: HMBP
Model: GL60AN
General data


Refrigerant:	R134a
Discharge element:	C
Cooling:	S
Maximum ambient temperature [ºC]:	50

Compressor’s data


Cylinder capacity [cm³]:	6
Displacement [m³/h]:	1
Weight [kg]:	9,9
Oil charge [cm³]:	345
Oil type:	ISO VG 19 ESTER

Engine’s data


Engine type:	RSIR
Power [KM]:	1/6
Starting element:	LST
Power supply:	220V 50Hz
Voltage range:	170-264
Locked rotor current [A]:	14,6
Running winding resistance (25ºC) [Ω]:	9,33
Starting winding resistance (25ºC) [Ω]:	10,81

Electrical data


Relays:	3003
Shielding element:	MRA38085, T0515, AF11BJ
Starting capacitor volume [μF]:

Connections

	milimeters	inches
Suction tube:	6,5
Service tube:	6,5
Discharge tube:	4,9

Mbsm_dot_pro_private_PDF_GL60AN Télécharger

Mbsm.pro, PDF, GL80AF , ZEM, EGL80AF, Compressors , GD40AF 1/9 , GL45AF 1/8 , GL60AF, GL70AF , GL70ANa 1/5 ,GL70AND, GL80AF 1/5

written by Lilianne | 20 December 2021

Mbsm_dot_pro_private_PDF_GLy80aa Télécharger

Mbsm_dot_pro_private_PDF_GLy80aa-compresseur-acc-cubigell Télécharger

Mbsm_dot_pro_private_PDF_GLy80aa-1 Télécharger

Mbsm.pro, PDF, Compressor Ermetic R134a H/MBP, Cubigel, GLy60aa

written by Lilianne | 20 December 2021

Mbsm_dot_pro_private_PDF_GLy60aa-compresseur-acc-cubigell-1 Télécharger

COMPRESSEUR, EMBRACO, ASPERA, NEK6213GK, HMBP, 1/2+ hp, 614 W

written by Lilianne | 20 December 2021

Puissance frigorifique à -10°C 1305 W
Puissance électrique à -10 °C 614 W
Puissance en cheval 1/2+ CV
Alimentation 220-240 V 50 Hz
Gaz R404a/R507 HMBP
Moyenne et haute pression
Complet avec starter, condensateur, boitier et système de fixation

Codes fabricants

ALPENINOX (anciennement NE9213GK)
ASCASO-VF.792 (anciennement NE9213GK)
ASPERA-NE9213GK (anciennement NE9213GK)
ELECTROLUX-85551 (anciennement NE9213GK)
EMBRACO-NE9213GK (anciennement NE9213GK)
EUNASA-21075 (anciennement NE9213GK)
EURFRIGOR-RB000447 (anciennement NE9213GK)
ITV-302035 (anciennement NE9213GK)
WHIRLPOOL-485409918033 (anciennement NE9213GK)
ZANUSSI-85551 (anciennement NE9213GK)
ALPENINOX-91161
ANGELO PO-3138720
ASPERA-NEK6213GK
ASPERA-NEK6213GK-CSIR
ELECTROLUX-91161
EMBRACO-NEK6213GK
EMBRACO-NEK6213GK-CSIR
EMMEPI-8C1300
FAST RICAMBI-605.125
GEV-605.125
MIGEL-1RF173
SAGI-3138720
UGOLINI-22807-13010
VND-605.125
ZANUSSI-91161

Compressor ASPERA NEK6213GK | NEK 6213 GK

Refigerant		R404A/R507
Working range[stC] MBP		-20 do +10
Nominal capacity [W] (evaporating temperature +7,2C, Condensing temperatur +54,4C)		1761
Power supply		220-240V 50Hz
Engine type		CSIR
Displacement [cm³]		12,11
Weight [kg]		11,6

Evaporating temperature +55 C

Evaporating Temperature	Cooling Capacity +/-5%			Power Consumption +/-5%	Current Consumption +/-5%	Gas Flow Rate +/-5%	Efficiency +/-7%
°C	(kcal/h)	(W)	(Btu/h)	(W)	(A)	(kg/h)	(kcal/Wh)	(W/W)
-20	514	598	2.040	569	3,87	16,07	0,90	1,05
-15	643	747	2.551	642	4,13	20,19	1,00	1,16
-10	793	922	3.148	717	4,41	25,09	1,11	1,29
-5	966	1.124	3.835	792	4,70	30,85	1,22	1,42
0	1.163	1.352	4.615	868	5,02	37,57	1,34	1,56
5	1.384	1.610	5.493	946	5,36	45,32	1,46	1,70
10	1.631	1.896	6.472	1.025	5,72	54,18	1,59	1,85

Substitutes for this compressor are: Electrolux/Cubigel MP12TB , Danfoss/Secop SC10DL , L’Unite Hermetique/Tecumseh CAE9470Z

Refrigerant:

R404A

,

R507

COMPRESSEUR EMBRACO NEK6213GK

220/240V 50Hz
puissance 1/2 Hp, le déplacement 12,12 cc
gaz réfrigérant R404a/R507 HMBP

LES CODES DE FABRICANT

091161 ALPENINOX

3138720 ANGELO PO

NEK6213GK ASPERA

NEK6213GK-CSIR ASPERA

091161 ELECTROLUX PROFESSIONNEL

NEK6213GK EMBRACO

NEK6213GK-CSIR EMBRACO

8C1300 EMMEPI

1RF173 MIGEL

3138720 SAGI

22807-13010 UGOLINI

091161 ZANUSSI

Alimentation	220/240 V-50 Hz-1 Ph
Chevaux	1/2 hp
Déplacement	12,11 cm3
Application	MHBP
Capacité frigorifique en conditions ASHRAE, R404A/R507	1,76 kW
Capacité frigorifique en conditions EN12900 MT, R404A/R507	0,97 kW
Réfrigérant	R404A, R452A, R507A
Aspiration	3/8″
Refoulement	1/4″
Poids	11,60 kg
Hauteur maximale	206 mm
LRA	19,30 A
Huile de recharge	350 cm3
Type d\’huile	POE 22 ester
Autres remarques	Accessoires de démarrage inclus
Technologie	Vitesse fixe
Type de refroidissement moteur	Ventilateur
Type moteur	CSIR
Type protection moteur	External

Mbsm_dot_pro_private_PDF_nek6213GK-Catalogue_Embraco Télécharger

Mbsm_dot_pro_private_PDF_nek6213GK-Catalogue_Embraco-1 Télécharger
