Mbsm.pro, Compressor, Panasonic, Gp21tb, Gp21fb, 5/8 hp, 415 kcal, 351 w (cap/cool), ELECTROLUX, HERMETIC, R134a, LBP, 220-240/1/50
![](https://www.mbsm.pro/wp-content/uploads/2024/02/Mbsm.pro-Compressor-Panasonic-Gp21tp-415-kcal-351-w-cap-cool-ELECTROLUX-HERMETIC-COMPRESSORS-R134a-LBP-220-240-1ph-50-1-1024x695.jpg)
![](https://www.mbsm.pro/wp-content/uploads/2024/02/Mbsm.pro-Compressor-Panasonic-Gp21tp-415-kcal-351-w-cap-cool-ELECTROLUX-HERMETIC-COMPRESSORS-R134a-LBP-220-240-1ph-50-1024x695.jpg)
The CA 2435Z-2 is a hermetic compressor manufactured by Kulthorn Kirby Co., Ltd.
ACC OF789 Refrigeration compressor R134a 220-240V/50Hz
1.Refrigerator Compressor
1).Excellent starting performance
2).Small space, light weight
3).Low noise
4). Little vibration
2.Feature:
1)Reasonable structure and compact size
2)High efficiency, energy saving
3)Stable performance, high security
4)Good adaptability of voltage
5)Excellent refrigeration
6)Wild range of refrigerant capacity
Model | Displacement | Height | Motor Type | Cooling capacity | COP |
Power Supply |
OF789 | 4.4cm3 | 174MM | RSIR | 110W | 1.08W/W | 220-240V/50Hz |
Start | RSIR |
Cooling | S. |
Refrigerant | R290 |
Performance | 175W (-35 ° C), 205W (-30 ° C), 265W (-25 ° C), 295W (-23.3 ° C), 335W (-20 ° C), 395W (-15 ° C), 455W (-10 ° C), 510W (-6.7 ° C), 560W (-5 ° C), 635W (0 ° C) |
Oil filling | 220g |
Power HP | 1/4 |
Input power | 196W (- 23.3 ° C), 255W (- 6.7 ° C) |
The step size | 6.5 cm³ |
Power supply | 220/240 V-50 Hz-1 Ph |
---|---|
Horsepower | 3/4 hp |
Displacement | 17,40 cm3 |
Application | LBP |
Cooling capacity at ASHRAE LT conditions, R404A/R507 | 0,78 kW |
Cooling capacity at EN12900 LT conditions, R404A/R507 | 0,42 kW |
Refrigerant | R404A, R452A, R507A |
Suction pipe | 3/8″ |
Discharge pipe | 1/4″ |
Weight | 17,00 kg |
Max height | 220 mm |
LRA | 25,00 A |
Recharge oil | 450 cm3 |
Type of oil | POE 22 ester |
Other remarks | Electrical components are included |
Technology | Fixed speed |
Type of motor cooling | Fan |
Motor type | CSIR |
Motor protection type | External |
Power supply | 220/240 V-50 Hz-1 Ph |
---|---|
Horsepower | 1/2 hp |
Displacement | 12,12 cm3 |
Application | MHBP |
Cooling capacity at ASHRAE conditions, R290 | 1,51 kW |
Cooling capacity at EN12900 MT conditions, R290 | 0,89 kW |
Refrigerant | R290 |
Suction pipe | 3/8″ |
Discharge pipe | 1/4″ |
Weight | 11,7 kg |
Max height | 206 mm |
LRA | 17,00 A |
Recharge oil | 350 cm3 |
Type of oil | POE 22 ester |
Other remarks | Electrical components are included |
Technology | Fixed speed |
Type of motor cooling | Fan |
Motor type | CSIR |
Motor protection type | External |
Power supply | 220/240 V-50 Hz-1 Ph |
---|---|
Horsepower | 1/2 hp |
Displacement | 8,78 cm3 |
Application | LBP |
Cooling capacity at ASHRAE LT conditions, R404A/R507 | 0,46 kW |
Cooling capacity at EN12900 LT conditions, R404A/R507 | 0,25 kW |
Refrigerant | R404A, R452A, R507A |
Suction pipe | 3/8″ |
Discharge pipe | 1/4″ |
Weight | 11 kg |
Max height | 200 mm |
LRA | 16,10 A |
Recharge oil | 350 cm3 |
Type of oil | POE 22 ester |
Other remarks | Electrical components are included |
Technology | Fixed speed |
Type of motor cooling | Fan |
Motor type | CSIR |
Motor protection type | External |
Power supply | 220/240 V-50 Hz-1 Ph |
---|---|
Horsepower | 1/3 hp |
Displacement | 12,11 cm3 |
Application | LBP |
Cooling capacity at EN12900 MT conditions, R134a | 0,37 kW |
Cooling capacity at ASHRAE LT conditions, R134a | 0,32 kW |
Cooling capacity at EN12900 LT conditions, R134a | 0,16 kW |
Refrigerant | R134a |
Suction pipe | 3/8″ |
Discharge pipe | 1/4″ |
Weight | 10,90 kg |
Max height | 200 mm |
LRA | 16,30 A |
Recharge oil | 350 cm3 |
Type of oil | POE 22 ester |
Other remarks | Electrical components are included |
Technology | Fixed speed |
Type of motor cooling | Fan |
Motor type | RSIR |
Motor protection type | External |
Cooling capacity (W) at -5°C: | 4202 |
---|---|
Cooling capacity (W) at -10°C: | 2256 |
Cooling capacity (W) at -15°C: | 1785 |
Cooling capacity (W) at -20°C: | 1381 |
Cooling capacity (W) at -25°C: | 1032 |
Cooling capacity (W) at 0°C: | 3452 |
Cooling capacity (W) at 5°C: | 2808 |
Cooling capacity (W) at 10°C: | 5069 |
Cooling capacity (W) at 15°C: | 6066 |
Champ d’application: | HBP |
Measurement conditions: | EN12900 |
Maker: | Tecumseh |
Condensing units Compressors: | Compressor |
Refrigerant: | R22 |
Series: | CAJ |
Condensing temperature: | 40 °C |
Tension: | 220-240V |
Type of build: | Alternative pistons |
