Mbsm.pro, Compressor, TWB1370MJS, TW381 – JS – 441, tw381-js-441, 180 w, 1/5 hp, lbp, Indesit, Ban134, R600
![](https://www.mbsm.pro/wp-content/uploads/2024/01/Mbsm_dot_pro_private_picture__TWB1370MJS-1024x784.jpg)
TECUMSEH TW 1374 Y 1/4 hp R134a motor compressor. TECUMSEH model TW 1374 with R134a refrigerant and 1/4 Hp with a performance of 165 frigories for two cold and No Frost refrigerators.
Medidas: 27 x 17 x 20 cm.
Weight: 15kg.
compressor capacity TW1374YS
From 1/8 to 1/5 of HP 3 meters of capillary 0.031 in inches or 0.80 millimeters
From 1/4 3 meters of capillary 0.036 in inches or 0.914 millimeters
From 1/3 3 meters of capillary 0.042 in inches or 1.067 millimeters
Compressor | EMBRACO |
---|---|
Template | NBM1119Y |
Height (mm) | |
Gas | R600a |
Voltage | 200-240V 50Hz / 230V 60Hz |
Application | LBP (Low Back Pressure) |
Test Condition | ASHRAE LBP 32 |
Displacement | 14.28 of the Italian Civil Code |
Motor | RSIR |
Power (HP) | |
Cap. Frigor. Watt | 233 |
Cap. Frigor. Kcal | 200 |
Cap. Frigor. Btu / h | 795 |
COP (W / W) | 1.44 |
Watt absorbed (W) | |
Device of Avv. | PTC |
Capacitor | |
Cooling type | |
Packaging (Pcs / Pallet) |
Gross weight | 11.97 kg |
Net weight | 11.97 kg |
Application energy level | High Energy-optimized |
Applications | LBP |
Auxiliary winding resistance (start winding) for single-phase compressors alt [Ohm] | 21.3 Ohm |
Base plate type | EU small |
Brand technique | Reciprocating compressor |
Capacity control | Fixed speed |
Colour | Black |
Compressor power supply [V/Ph/Hz] | 220-240/1/50 |
Configuration code | Single |
Cut in current LST [A] | 9.3 A |
Description | NLX15KK.2 |
Discharge connection angle [°] | 21 ° |
Discharge connection comments | Al-cap |
Discharge connection diameter [mm] | 5 mm |
Discharge connection material | Cu-plated steel |
Economizer | No |
Free gas volume [cm3] | 2360 cm³ |
Frequency [Hz] | 50 |
Height from baseplate [mm] | 197 mm |
High value of nominal voltage at 50Hz [V] | 240 V |
High value of voltage range at 50Hz [V] | 255 V |
Length [mm] | 252 mm |
Liquid injection | No |
Low value of nominal voltage at 50Hz [V] | 220 V |
Low value of voltage range at 50Hz [V] | 187 V |
LRA LST [A] | 5.6 A |
Main winding resistance for single-phase compressors [Ohm] | 11.3 Ohm |
Model number | NLX15KK.2 |
Motor type | RSCR |
No. of phases (compressor) | 1 |
Nominal cooling capacity 60 kBTU/h | 5.18 kBtu/h |
Nominal cooling capacity at 60Hz | 1.5 kW |
Oil quantity [cm3] | 270 cm³ |
Oil type | POE |
Packing format | Single pack |
Packing quantity | 1 |
Process connection angle [°] | 25 ° |
Process connection comments | Al-cap |
Process connection diameter [mm] | 6.2 mm |
Process connection material | Cu-plated steel |
Refrigerant | R600a |
Refrigerant charge [kg] [Max] | 0.15 kg |
RLA | 1.10 A |
Rotational speed at 50Hz [rpm] | 3000 rpm |
Run capacitor capacitance | 4 µF |
Segment usage | Refrigeration LT |
Speed Platform | Fixed-speed |
Suction connection angle [°] | 2 ° |
Suction connection comments | Al-cap |
Suction connection diameter [mm] | 6.2 mm |
Suction connection material | Cu-plated steel |
Swept volume [cm3] | 14.65 cm³ |
Technology | Reciprocating |
Total height [mm] | 203 mm |
Type | NL |
Type designation | Compressor |
Voltage 50Hz [V] | 220 V |
Voltage 50Hz [V] [Max] | 240 V |
Width [mm] | 166 mm |
Winding temperature short term [°C] [Max] | 110 °C |
Winding temperature stat [°C] [Max] | 95 °C |
Thermostat réglable
Indicateur de température partie réfrigérateur
