Copeland Scroll ZP90KCE TFD

Refrigeration Type : R410A

Cooling Efficiency (EER) : 10.7

Capacity Range (BTU) : 74,500

Voltage : 380-420V ; 50Hz

Phase : 3

Application : Airconditioning

Compressor Copeland Scroll, ZP90KCE-TFD-425, R410A, 380V, 50Hz
Stroke Volume: 22,1 m3 / h,
Connectors: 1.1 / 8 “x7 / 8”,
Oil Capacity: 2.5 dm3 ,
Weight: 56.7 kg.
Noise level: 61 dB

Shipping Class Standard
Scope Of Application HBP
Lieferzeit Ca. 10-14 Tage
Type Of Construction Scroll
Maker Copeland
Manufacturer No. ZP90KCE-TFD-425
Style 1
Refrigerants R410A
Series ZP
Condensing Units Compressors Compressors
Suspense 380-420V
Weight In Kg 57

Mbsm_dot_pro_private_PDF_ZP90KCETélécharger
