The dc GQY99AA compressor is intended especially for use in freezer,refrigeration cabinet,showcase,drinking machine,ice machine.

       Advantages

A.R134a refrigeration compressor,1/4HP
B.reasonable structure and compact size
C.high efficiency,energy saving
D.reliable security
E.good adjustment with any temperature

Refrigeration compressor,LBP R134a refrigeration compressor

model number: GQY99AA

1. stable performance,high security
2. High efficiency, low power consumption
3.good adaptability of volty

4.certificate:RoHS, VDE, CE, CCCs,UR, UL

Details:

 LBP,R134a compressor,use for cabinet,show case,liquor cabinet and other medium and large sized refrigeration machines.

Test Conditions(Ashrae):

Evaporating temperature:-23.3ºC

Condensing temperature:54.4ºC

Subcooling temperature:32.2ºC

Suction temperature:32.2ºC

Ambient temperature:32.2ºC

KONOR, COMPRESSOR, GQR80AA,  R134A, LBP, 240V,  50Hz,  8.1cm3, 1/4HP, 198W, -KONOR CATALOGE pdf

Parameter

Product type	Refrigeration Compressor
Series	LX Series
Size	Large Frame
Displacement	8.6 cc/rev
Refrigerant	R134a
Improvement order	Cu Wire
Rated voltage	220-240 V
Frequency	50 Hz
Motor type	RSIR, PTC
Application	LBP, Middle & Large size refrigerator, freezer & Showcase
Evaporating temperature	-23.3°C
Condensing temperature	54.4°C
Ambient temperature	32.2°C
