R134a S-Series (Induction)

Performance

Notes: All data covered by this catalogue are given as general information only.

The product specifications and availability are subjected to change without notice.

Application : Low Back Pressure

Refrigerant : R134a (CF

3CH2F)

Evaporator Temperature Range : -35°C to -5°C

Series Model

Displacement

(cm

3

)

Voltage /

Frequency

Motor

Type

ASHRAE CECOMAF

Capacity COP Capacity COP

W W/W W W/W

SB

SB24C45GAU6 2.4 115V 60Hz

RSIR 50 0.85 - -

RSCR - - - -

SB24C50GA00 2.4 100V 50/60Hz

RSIR 37 / 45 0.60 / 0.70 - -

RSCR - - - -

SB24C50GAU6 2.4 115V 60Hz

RSIR 45 0.80 - -

RSCR - - - -

SB24C50GAW5 2.4 220/240V 50Hz

RSIR 37 / 37 0.71 / 0.64 - -

RSCR - - - -

SB30C50GAU6 3.0 115V 60Hz

RSIR 72 0.93 - -

RSCR - - - -

SB30C50GAW5 3.0 220/240V 50Hz

RSIR 60 / 60 0.81 / 0.74 - -

RSCR - - - -

SB30C55GAT6 3.0 110V 60Hz

RSIR 72 0.83 - -

RSCR - - - -

SB30C56GA00 3.0 100V 50/60Hz

RSIR 60 / 72 0.82 / 0.91 - -

RSCR - - - -

SB30C65GAX6 3.0 220V 60Hz

RSIR 72 0.95 - -

RSCR - - - -

SB30C70GAX0 3.0 220V 50/60Hz

RSIR 60 / 72 0.88 / 0.97 - -

RSCR - - - -

SB35C65GAU6 3.5 115V 60Hz

RSIR 88 1.05 - -

RSCR - - - -

SB35C65GAW5 3.5 220/240V 50Hz

RSIR 76 / 76 0.96 / 0.90 - -

RSCR - - - -

SB35C66GA00 3.5 100V 50/60Hz

RSIR 76 / 88 0.84 / 0.95 - -

RSCR - - - -

SB35C67RAY5 3.5 230/240V 50Hz

RSIR 76 / - 0.99 / - - -

RSCR 76 / - 1.06 / - - -

SB35C70GAX6 3.5 220V 60Hz

RSIR 88 1.00 - -

RSCR - - - -

R134a S-Series (Induction)

Performance

Notes: All data covered by this catalogue are given as general information only.

The product specifications and availability are subjected to change without notice.

Application : Low Back Pressure

Refrigerant : R134a (CF

3CH2F)

Evaporator Temperature Range : -35°C to -5°C

Series Model

Displacement

(cm

3

)

Voltage /

Frequency

Motor

Type

ASHRAE CECOMAF

Capacity COP Capacity COP

W W/W W W/W

SB

SB35C76GAT6 3.5 110V 60Hz

RSIR 88 1.03 - -

RSCR - - - -

SB35C80GAX0 3.5 220V 50/60Hz

RSIR 76 / 88 1.02 / 1.06 - -

RSCR - - - -

SB39C76GA00 3.9 100V 50/60Hz

RSIR 81 / 99 0.91 / 1.00 - -

RSCR - - - -

SB43C10GAX0 4.3 220V 50/60Hz

RSIR 95 / 120 1.04 / 1.11 - -

RSCR - - - -

SB43C75GAU6 4.3 115V 60Hz

RSIR 120 1.09 - -

RSCR - - - -

SB43C77RB00 4.3 100V 50/60Hz

RSIR - - - -

RSCR 95 / 120 1.06 / 1.17 - -

SB43C77RAU6 4.3 115V 60Hz

RSIR - - - -

RSCR 120 1.14 - -

SB43C80GAW5 4.3 220/240V 50Hz

RSIR 95 / 95 1.03 / 0.98 - -

RSCR - - - -

SB43C86GA00 4.3 100V 50/60Hz

RSIR 95 / 120 0.98 / 1.11 - -

RSCR - - - -

SB43C90RA00 4.3 100V 50/60Hz

RSIR - - - -

RSCR 95 / 120 1.06 / 1.17 - -

SB43C90RAY5 4.3 230/240V 50Hz

RSIR 95 1.02 - -

RSCR 95 1.09 - -

SB43C92GAX6 4.3 220V 60Hz

RSIR 120 1.09 - -

RSCR - - - -

SB48C10RAY5 4.8 230/240V 50Hz

RSIR 108 / - 1.01 / - - -

RSCR 108 / - 1.07 / - - -

SB48C12GAX5 4.8 220V 50Hz

RSIR 110 1.06 - -

RSCR - - - -

SB48C12GAX6 4.8 220V 60Hz

RSIR 133 1.10 - -

RSCR - - - -

R134a S-Series (Induction)

Performance

Notes: All data covered by this catalogue are given as general information only.

The product specifications and availability are subjected to change without notice.

Application : Low Back Pressure

Refrigerant : R134a (CF

3CH2F)

Evaporator Temperature Range : -35°C to -5°C

Series Model

Displacement

(cm

3

)

Voltage /

Frequency

Motor

Type

ASHRAE CECOMAF

Capacity COP Capacity COP

W W/W W W/W

SB

SB48C90RAT6 4.8 110V 60Hz

RSIR - - - -

RSCR 133 1.22 - -

SB48C90RAU6 4.8 115V 60Hz

RSIR - - - -

RSCR 133 1.17 - -

SB48C95GAW5 4.8 220/240V 50Hz

RSIR 110 / 110 1.03 / 0.99 - -

RSCR - - - -

SB48C97RA00 4.8 100V 50/60Hz

RSIR - - - -

RSCR 110 / 133 1.06 / 1.15 - -

SB51C12RA00 5.1 100V 50/60Hz

RSIR - - - -

RSCR 125 / 148 1.03 / 1.15 - -

SB51C90RAU6 5.1 115V 60Hz

RSIR - - - -

RSCR 142 1.17 - -

SB51C97RA00 5.1 100V 50/60Hz

RSIR - - - -

RSCR 117 / 142 1.06 / 1.15 - -

SF

SF30C44RAU6 3.0 115V 60Hz

RSIR - - - -

RSCR 88 1.28** - -

SF35C83GAX6 3.5 220V 60Hz

RSIR 109 1.12 - -

RSCR - - - -

SF39C60RA00 3.9 100V 50/60Hz

RSIR - - - -

RSCR 107 / 129** 1.39 / 1.47** - -

SF39C60RAW5 3.9 220/240V 50Hz

RSIR - - - -

RSCR 105 / 105 1.38 / 1.36 - -

SF39C62GA00 3.9 100V 50/60Hz

RSIR 107 / 129 1.25 / 1.32 - -

RSCR - - - -

SF39C67GAU6 3.9 115V 60Hz

RSIR 129 1.44 - -

RSCR - - - -

SF39C74RAX5 3.9 220V 50Hz

RSIR - - - -

RSCR 105 1.40 - -

SF39C78GAX5 3.9 220V 50Hz

RSIR 105 1.25 - -

RSCR - - - -

R134a S-Series (Induction)

Performance

Notes: All data covered by this catalogue are given as general information only.

The product specifications and availability are subjected to change without notice.

Application : Low Back Pressure

Refrigerant : R134a (CF

3CH2F)

Evaporator Temperature Range : -35°C to -5°C

Series Model

Displacement

(cm

3

)

Voltage /

Frequency

Motor

Type

ASHRAE CECOMAF

Capacity COP Capacity COP

W W/W W W/W

SF

SF39C74RAX5 3.9 220V 50Hz

RSIR - - - -

RSCR 105 1.40 - -

SF39C78GAX5 3.9 220V 50Hz

RSIR 105 1.25 - -

RSCR - - - -

SF43C10RAX6 4.3 220V 60Hz

RSIR - - - -

RSCR 147 1.32 - -

SF43C72RAU6 4.3 115V 60Hz

RSIR - - - -

RSCR 145 1.44 - -

SF43C76RA00 4.3 110V 60Hz

RSIR - - - -

RSCR 145 1.41 - -

SF43C76RAX5 4.3 220V 50Hz

RSIR 121 1.29 - -

RSCR 121 1.38 - -

SF43C83RAW5 4.3 220/240V 50Hz

RSIR 121 / 121 1.29 / 1.25 - -

RSCR 121 / 121 1.38 / 1.34 - -

SF48C10RAX5 4.8 220V 50Hz

RSIR - - - -

RSCR 139 1.36 - -

SF48C91RAW5 4.8 220/240V 50Hz

RSIR - - - -

RSCR 138 / 138 1.39 / 1.35 - -

SF51C10RAX5 5.1 220V 50Hz

RSIR 148 1.38 - -

RSCR - - - -

SF51C91RAW5 5.1 220/240V 50Hz

RSIR - - - -

RSCR 147 / 147 1.40 / 1.36 - -

SF51C97RAU6 5.1 115V 60Hz

RSIR - - - -

RSCR 176 1.44 - -

SBA SBA30C45GPE 3.0 220V 50/60Hz

RSIR 70 / 85 0.88 / 0.97 - -

RSCR - - - -

SBH

SBH24C40GLU 2.4 115V 60Hz

RSIR 55 0.80 - -

RSCR - - - -

SBH30C52GLE 3.0 220V 50/60Hz

RSIR 68 / 80 0.88 / 0.97 - -

RSCR - - - -

R134a S-Series (Induction)

Performance

Notes: All data covered by this catalogue are given as general information only.

The product specifications and availability are subjected to change without notice.

Application : Low Back Pressure

Refrigerant : R134a (CF

3CH2F)

Evaporator Temperature Range : -35°C to -5°C

Series Model

Displacement

(cm

3

)

Voltage /

Frequency

Motor

Type

ASHRAE CECOMAF

Capacity COP Capacity COP

W W/W W W/W

SBH

SBH30C52GPE 3.0 220V 50/60Hz

RSIR 68 / 80 0.88 / 0.97 - -

RSCR - - - -

SBH30C56GAJ 3.0 100V 50/60Hz

RSIR 68 / 80 0.86 / 0.99 - -

RSCR - - - -

SBH30C58GLU 3.0 115V 60Hz

RSIR 80 0.93 - -

RSCR - - - -

SBH30C62GAP 3.0 220V 60Hz

RSIR 80 0.92 - -

RSCR - - - -

SBH30C62GLP 3.0 220V 60Hz

RSIR 80 0.92 - -

RSCR - - - -

SBH30C63RPP 3.0 220V 60Hz

RSIR - - - -

RSCR 80 1.00 - -

SBH30C65GAE 3.0 220V 50/60Hz

RSIR 70 / 82 0.88 / 0.97 - -

RSCR - - - -

SBH35C57GPW 3.5 220/240V 50Hz

RSIR 84 / 84 0.96 / 0.93 - -

RSCR - - - -

SBH35C68RLE 3.5 220V 50/60Hz

RSIR - - - -

RSCR 84 / 100 1.02 / 1.06 - -

SBH35C81GAE 3.5 220V 50/60Hz

RSIR 86 / 102 1.02 / 1.06 - -

RSCR - - - -

SBH35C81GAP 3.5 220V 60Hz

RSIR 100 1.00 - -

RSCR - - - -

SBH35C83RLP 3.5 220V 60Hz

RSIR - - - -

RSCR 100 1.00 - -

SBH43C10RLP 4.3 220V 60Hz

RSIR - - - -

RSCR 125 1.09 - -

SBH43C73RLE 4.3 220V 50/60Hz

RSIR - - - -

RSCR 106 / 125 1.07 / 1.18 - -

SBH43C90RAJ 4.3 100V 50/60Hz

RSIR - - - -

RSCR 106 / 125 1.10 / 1.20 - -

R134a S-Series (Induction)

Performance

Notes: All data covered by this catalogue are given as general information only.

The product specifications and availability are subjected to change without notice.

Application : Low Back Pressure

Refrigerant : R134a (CF

3CH2F)

Evaporator Temperature Range : -35°C to -5°C

Series Model

Displacement

(cm

3

)

Voltage /

Frequency

Motor

Type

ASHRAE CECOMAF

Capacity COP Capacity COP

W W/W W W/W

SBH

SBH43C95GAP 4.3 220V 60Hz

RSIR 125 1.09 - -

RSCR - - - -

SBH43C97GAE 4.3 220V 50/60Hz

RSIR 106 / 125 1.04 / 1.11 - -

RSCR - - - -

SBH48C11RPX 4.8 220V 50Hz

RSIR - - - -

RSCR 118 1.12 - -

SBH48C11RLX 4.8 220V 50Hz

RSIR - - - -

RSCR 118 1.12 - -

SBH48C12GAX 4.8 220V 50Hz

RSIR 119 1.04 - -

RSCR - - - -

SBH51C10RAJ 5.1 100V 50/60Hz

RSIR - - - -

RSCR 126 / 147 1.08 / 1.19 - -

SFH

SFH39C63RAU 3.9 115V 60Hz

RSIR - - - -

RSCR 131 1.44 - -

SFH39C64RAW 3.9 220/240V 50Hz

RSIR - - - -

RSCR 106 / 106 1.38 / 1.36 - -

SFH39C73RLX 3.9 220V 50Hz

RSIR - - - -

RSCR 108 1.27 - -

SFH43C73RAU 4.3 115V 60Hz

RSIR - - - -

RSCR 148 1.44 - -

SFH43C76GAE 4.3 220V 50/60Hz

RSIR 121 / 148 1.21 / 1.28 - -

RSCR - - - -

SFH43C80RAW 4.3 220/240V 50Hz

RSIR - - - -

RSCR 121 / 121 1.38 / 1.34 - -

SFH48C11RAX 4.8 220V 50Hz

RSIR - - - -

RSCR 141 1.27 - -

SFH48C87RAW 4.8 220/240V 50Hz

RSIR - - - -

RSCR 140 / 140 1.39 / 1.35 - -

SFH48C99RAX 4.8 220V 50Hz

RSIR - - - -

RSCR 141 1.36 - -

R134a S-Series (Induction)

Performance

Notes: All data covered by this catalogue are given as general information only.

The product specifications and availability are subjected to change without notice.

Application : Low Back Pressure

Refrigerant : R134a (CF

3CH2F)

Evaporator Temperature Range : -35°C to -5°C

Series Model

Displacement

(cm

3

)

Voltage /

Frequency

Motor

Type

ASHRAE CECOMAF

Capacity COP Capacity COP

W W/W W W/W

SFH

SFH51C11RAX 5.1 220V 50Hz

RSIR - - - -

RSCR 150 1.30 - -

SFH51C91RAU 5.1 115V 60Hz

RSIR - - - -

RSCR 179 1.44 - -

SFH51C99RAX 5.1 220V 50Hz

RSIR - - - -

RSCR 150 1.38 - -

SFJ

SFJ39C69RLU 3.9 115V 60Hz

RSIR - - - -

RSCR 132 1.41 - -

SFJ39C72RLW 3.9 220/240V 50Hz

RSIR - - - -

RSCR 105 / 105 1.35 / 1.29 - -

SFJ43C69RLJ 4.3 100V 50/60Hz

RSIR - - - -

RSCR 121 / 150 1.36 / 1.44 - -

SFJ48C10RLX 4.8 220V 50Hz

RSIR - - - -

RSCR 141 1.37 - -

SFJ48C87RLW 4.8 220/240V 50Hz

RSIR - - - -

RSCR 142 / 142 1.36 / 1.28 - -

SFJ51C10RLX 5.1 220V 50Hz

RSIR - - - -

RSCR 150 1.38 - -

SFJ51C85RLW 5.1 220/240V 50Hz

RSIR - - - -

RSCR 150 / 150 1.38 / 1.33 - -

SFJ51C87RLW 5.1 220/240V 50Hz

RSIR - - - -

RSCR 151 / 151 1.38 / 1.30 - -

SFJ51C91RAU 5.1 115V 60Hz

RSIR - - - -

RSCR 182 1.44 - -

SFK

SFK39C71RPW 3.9 220/240V 50Hz

RSIR - - - -

RSCR 108 / 108 1.35 / 1.29 - -

SFK39C73RPX 3.9 220V 50Hz

RSIR - - - -

RSCR 108 1.32 - -

SFK43C82GPX 4.3 220V 50Hz

RSIR 124 1.24 - -

RSCR - - - -

R134a S-Series (Induction)

Performance

Notes: All data covered by this catalogue are given as general information only.

The product specifications and availability are subjected to change without notice.

Application : Low Back Pressure

Refrigerant : R134a (CF

3CH2F)

Evaporator Temperature Range : -35°C to -5°C

Series Model

Displacement

(cm

3

)

Voltage /

Frequency

Motor

Type

ASHRAE CECOMAF

Capacity COP Capacity COP

W W/W W W/W

SFK

SFK48C94RPX 4.8 220V 50Hz

RSIR - - - -

RSCR 148 1.35 - -

SFK51C94RPX 5.1 220V 50Hz

RSIR - - - -

RSCR 157 1.35 - -

SFK57C11RLX 5.7 220V 50Hz

RSIR - - - -

RSCR 176 1.39 - -

SHH

SHH43C72RAU 4.3 115V 60Hz

RSIR - - - -

RSCR 148 1.49 - -

SHH48C97RAU 4.8 115V 60Hz

RSIR - - - -

RSCR 169 1.49 - -

SHH51C97RAU 5.1 115V 60Hz

RSIR - - - -

RSCR 179 1.49 - -

SHJ SHJ51C90RAU 5.1 115V 60Hz

RSIR - - - -

RSCR 182 1.49 - -

SHK SHK51C92RLU 5.1 115V 60Hz

RSIR - - - -

RSCR 205(AHAM) 1.75(AHAM) - -

SJJ

SJJ39C56RBJ 3.9 100V 50/60Hz

RSIR - - - -

RSCR 105 / 132 1.51 / 1.53 - -

SJJ39C58RBU 3.9 115V 60Hz

RSIR - - - -

RSCR 132 1.58** - -

SJJ43C78RBU 4.3 115V 60Hz

RSIR - - - -

RSCR 150 1.58** - -

SJJ51C88RAU 5.1 115V 60Hz

RSIR - - - -

RSCR 182 1.58 - -

R134a S-Series (Induction)

Performance

Notes: All data covered by this catalogue are given as general information only.

The product specifications and availability are subjected to change without notice.

Application : High Back Pressure

Refrigerant : R134a (CF

3CH2F)

Evaporator Temperature Range : -5°C to 15°C

Series Model

Displacement

(cm

3

)

Voltage /

Frequency

Motor

Type

ASHRAE CECOMAF

Capacity COP Capacity COP

W W/W W W/W

SB SB35K81GA00 3.5 100V 50/60Hz

RSIR 329 / 382 1.79 / 1.84 - -

RSCR - - - -

OPERATING VOLTAGE RANGE

For 100V 50/60Hz : 90V~110V

For 110V 60Hz : 88V~121V, 90V~110V, 99V~121V, 90V~121V

For 115V 60Hz : 103V~127V

For 220V 50Hz : 170V~250V

For 220-240V 50Hz : 198V~264V

For 230-240V 50Hz : 207V~264V

For 220V 50/60Hz : 170V~250V, 198V~242V

For 220V 60Hz : 170V~250V

** Performance Data using Eco Relay

LOW BACK PRESSURE

TESTING CONDITION AHAM ASHRAE CECOMAF

Condensing Temperature: 40.6 °C 54.4 °C 55 °C

Evaporating Temperature: -23.3 °C -23.3 °C -25 °C

Gas Superheated to: 32.2 °C 32.2 °C 32 °C

Liquid Subcooled to: 32.2 °C 32.2 °C 32 °C

Ambient Temperature: 32.2 °C 32.2 °C 32 °C

HIGH BACK PRESSURE

TESTING CONDITION ASHRAE

Condensing Temperature: 54.4 °C

Evaporating Temperature: 7.2 °C

Gas Superheated to: 35.0 °C

Liquid Subcooled to: 46.1 °C

Ambient Temperature: 35.0 °C

R134a SB-Series

Dimensions

Notes: All data covered by this catalogue are given as general information only.

The product specifications and availability are subjected to change without notice.

Appearance (Representative)

Rated Voltage / Frequency

Dimension (mm) Mount

A B C Dia. (mm) Pitch (mm)

As indicated in the earlier table 170 192 150

Ø19 * 4 102 * 165

Ø16 * 4 70 * 170

Tube Dimension (Representative)

Rated Voltage / Frequency

ID / OD (mm)

Location of Suction Tube

Discharge Suction Process

As indicated in the earlier table 4.9 / 7.0 6.5 / 7.94 6.5 / 7.94 Left Side

Suction Tube

R134a SF / SH / SJ-Series

Dimensions

Notes: All data covered by this catalogue are given as general information only.

The product specifications and availability are subjected to change without notice.

Appearance (Representative)

Rated Voltage / Frequency

Dimension (mm) Mount

A B C Dia. (mm) Pitch (mm)

As indicated in the earlier table 170 204 150 Ø16 * 6 70 * 170

Tube Dimension (Representative)

Rated Voltage / Frequency

ID / OD (mm)

Location of Suction Tube

Discharge Suction Process

As indicated in the earlier table 4.9 / 7.0 6.5 / 7.94 6.5 / 7.94 Left Side

Suction Tube
