Data Sheet
| Power supply | 220-240V Δ / 380-420 Y 3Ph 50Hz (265-290V Δ / 440-480V Y 3Ph 60Hz) |
|---|---|
| Horsepower | 4 hp |
| Displacement | 23,9 m3 |
| Cooling capacity at LT conditions, R404A | 4,41 kW |
| Cooling capacity at ARI conditions, R134a | 12,91 kW |
| Refrigerant | R134a, R22, R404A, R407A, R407F, R448A, R449A, R450A, R452A, R507, R513A |
| Suction pipe | 1 1/8″ |
| Discharge pipe | 3/4″ |
| Weight | 79 kg |
| LRA | 53,2 A |
| MCC | 11,7 A |
| Type of oil | FRASCOLD POE 32 |
| Accessories | Control capacity (SPFR0010), Control capacity 50%, Crankcase heater 70W (SPFR0014), Head Fan |
| Application | LBP |
| Technology | Fixed speed |
| Previous version | Q4-24Y |
| Lubrication mode | Without oil pump |
| High pressure design | 30 bar |
| Motor protection type | INT69 Diagose |
| Type of motor cooling | Suction gas |
| Protection type | IP56 |
| Speed | 1450 rpm |
